Sea-doo RXP-X 255 and 255 RS, 2010 10- Electrical System Diagram

MODULE SUPPORT - Call your local BRP dealership

278002699

Unavailable

Pop Rivet 3/16"

293150123

$4.29

Hex. Screw 10-14 X 7/8”

211000023

$3.59

Flat Washer M6, Stainless

234062600

$0.77

Interrupter T.O.P.S.

278001992

$74.49

Voltage Regulator | For replacement, refer to service bulletin 2005-5

710001103

$142.99

TORX SCREW 10-14 X 1-1/8 - Call your local BRP dealership

250000236

Unavailable

Flat Washer M6, Stainless

234062600

$0.77

Starter Relay

278003012

$42.49

Diagnostic Connector

278002704

$19.49

Battery, 30 Amperes

278001882

$184.01

Battery Bolt Kit

250000282

$7.29

Hex. Screw M8 X 40, Scotch Grip

207284060

$2.24

Flat Washer 8 mm, Stainless

234082600

$2.43

Battery Support

278003306

$20.99

Hex. Screw M6 X 45

207164560

$1.89

Elastic Stop Nut M6, Brass

232561200

$4.23

Flat Washer M6, Stainless

234062600

$0.77

Grommet

293720029

$1.59

CHECK VALVE - Call your local BRP dealership This part replaces 275500167.

275500499

Unavailable

HOSE 6 MM - Call your local BRP dealership

275500446

Unavailable

Tie Wrap 94 mm | 4X4

293750001

$1.03

Elastic Stop Nut M6, Brass

232561200

$4.23

Tie-Rap 180 mm

414115200

$0.11

Tie Wrap 368 mm

293750008

$1.04

GROUND CABLE ASS'Y - Call your local BRP dealership

278002177

Unavailable

Hex. Screw M10 X 20, Scotch Grip

207302060

$4.02

Flat Washer 10 mm, Stainless

234000600

$1.46

STARTER CABLE - Call your local BRP dealership

278002267

Unavailable

Elastic Stop Nut M6, Brass

232561200

$4.23

Stainless Flat Washer M6

234061600

$0.33

Was 293550004 Dielectric Grease, 150 g

219704453

$38.99

Female Terminal Housing, 3 Circuits | XT Models

278000281

$9.85

Hex. Screw M6 X 12, Scotch Grip

207361260

$0.58

Stainless Flat Washer M6

234061600

$0.33

RETAINER - Call your local BRP dealership

275500553

Unavailable

Hex. Flange Screw K40 X 16

241141660

$1.48

Digital Multifunction Gauge | SERV

278002270

$1.00

Check Valve

275500398

$10.99

Tie Wrap 142 mm

293750002

$1.25

Gauge Bezel, Chrome

278002144

$38.99

Hex. Flange Screw K40 X 25

241142560

$2.64

TRIM - Call your local BRP dealership

293830113

Unavailable

Safety Nut (DESS Switch)

278002963

$3.28

Safety Lanyard, Antitheft This part replaces 278001543.

278002199

$84.99

SAFETY LANYARD, LEARNING KEY - Call your local BRP dealership

278002406

$53.99

Speed Sensor

278001993

$169.99

PHILLIPS SCREW #10 X 7/8 - Call your local BRP dealership

211000021

Unavailable

Silicone Sealant 51388, 300 ml

296000309

$36.99

Mount Dart

293730040

$1.04

Plastic Nut

278002291

$9.32

ADHESIVE LOCTITE 425 20ML - Call your local BRP dealership

219704457

$54.99

Harness Ass'y | Includes 1 to 2025

278002269

$769.99

Steering Harness | Includes 1 to 15

278002384

$469.99

Digital Multifunction Gauge Harness | Includes 16 to 21

278002111

$49.99
