Sea-doo RXP, 2016 Steering Diagram

#

Description
Price

1

Socket Screw M6 X 16

205061660

$1.43

2

SOCKET HEAD SCREW M8 X 40 - Call your local BRP dealership

205084060

Unavailable

3

Socket Head Screw M6 X 20, Scotch Grip

205562060

$0.72

4

Hex. Screw M6 X 35

207063560

$2.12

4

Hex. Screw M6 X 35

207163560

$1.34

5

Hex. Screw M6 X 40

207064060

$1.61

6

Hex. Screw M6 X 50

207165060

$0.87

7

Hex. Screw 10-14 X 7/8”

211000023

$3.34

8

Hex. Nut 1/4"-28

211100056

$0.64

9

Elastic Stop Nut M6, Brass

232561200

$4.03

10

Flat Washer 4 mm, Stainless

234042600

$1.06

11

Flat Washer 5 mm, Stainless

234052600

$0.73

12

Stainless Flat Washer M6

234061600

$0.28

13

Flat Washer M6, Stainless

234062600

$0.73

14

Flat Washer M8, Stainless

234080600

$1.43

15

Hex. Flange Screw K40 X 25

241142560

$2.49

16

Hex Cap Screw M6X1.0X45 S.Grip

245064560

$1.79

17

Hex. Screw M6 X 30, Scotch Grip

250000002

$0.87

18

Flat Washer M6.6 X 22

250200022

$2.15

19

M6 Nut Housing Ass'y | Includes 290 to 290b

269500252

$6.24

20

Housing Nut M6 | Included 550f to 550f2

269502408

$5.07

21

Black, Cap

277000203

$8.58

22

Ball Joint

277000775

$46.24

24

Ajustment Knob

277000782

$18.63

25

Half Ring

277001527

$9.58

26

Steering Cable Ass'y | Includes 540 TO 540d

277001578

$194.75

27

Wiper Rod

277001582

$10.13

28

End Piece

277001583

$12.79

29

Wear Ring

277001653

$11.18

30

Spacer

277001654

$13.09

31

Thrust Support Ass'y

277001655

$26.09

32

Handle Pad

277001683

$82.06

33

Steering Column

277001685

$221.61

34

Upper Housing RH

277001688

$98.48

34

LH UPPER HOUSING - Call your local BRP dealership

277001686

Unavailable

36

Steering Cable Lock This part replaces 277000784.

277001729

$11.96

37

Wear Ring

277002318

$14.27

38

Insert Grip Handle

277001863

$8.83

39

Steering Arm Support Ass'y | Includes 460 TO 460c

277001872

$35.04

40

Red, Knob Switch

277001887

$8.66

41

FRONT EXTENSION BLOC - Call your local BRP dealership

277001909

Unavailable

42

Steering Support Ass'y | Includes 710 TO 710b

277001913

$103.70

43

AESTHETIC CAP - Call your local BRP dealership

277001919

Unavailable

44

RADIO FREQUENCY KEY SUPPORT - Call your local BRP dealership

277001920

Unavailable

45

Throttle Handle

277001944

$35.04

46

Reverse Handle

277001945

$39.52

47

Deep Black, RH Handle Grip

277001946

$17.88

47

Deep Black, LH Handle Grip

277001958

$17.88

49

Deflector

293000117

$27.58

50

GASKET PAC = 1.0m - Call your local BRP dealership

293250008

Unavailable

52

Grommet

293720086

$11.69

53

Cable Grommet

293720090

$7.57

54

Tie Wrap 368 mm

293750008

$0.97

56

Rubber Washer

293830063

$1.73

57

Bushing

293900091

$3.84

58

Tie-Rap 180 mm

414115200

$0.10

59

Cap

517302716

$4.28

60

REAR EXTENSION BLOCK - Call your local BRP dealership

277001926

Unavailable

61

Torx-Button M/S M8 X 40 Stlss S.Gri

250000845

$3.73

62

LH Lower Housing This part replaces 277001965.

277001950

$138.03

62

RH LOWER HOUSING - Call your local BRP dealership This part replaces 277001966.

277001951

Unavailable

63

RH Housing Cover

277001718

$117.88

63

LH HOUSING COVER - Call your local BRP dealership

277001794

Unavailable
