Description

Price

1

Oil Pump Housing

420812723

$105.19

2

Plug Screw M10 X 1

420641323

$13.18

3

Oil Pump Shaft

420837543

$56.69

4

Oil Pump Rotor 16 mm

420956675

$33.55

5

Oil Pump Cover

420811851

$31.31

6

Torx Flange Screw M6 X 16

420641048

$2.82

7

Oil Sieve

420856520

$24.60

8

Oil Suction Pump Gasket | Included in gasket kit

420631486

$9.03

9

Torx Flange Screw M6 X 25

420641238

$3.07

10

OIL FILLER TUBE ASS'Y - Call your local BRP dealership | Includes 9 to 10

420856511

$34.30

11

Gasket

420430240

$4.15

12

Torx Flange Screw M6 X 45

420641198

$3.88

13

Plug Cover, Yellow

420956923

$22.36

14

Retaining Band

420660620

$7.01

15

Loctite 243, 10 ml

293800060

$21.49

16

OIL 4T 12X1 BLEND QUART - Call your local BRP dealership

293600121

Unavailable

Sea-doo RXP, 2006 Oil Separator Diagram
