Yamaha RX10RYR (APEX_RTX) 8FR9 2009 CONTROL CABLE Diagram

#

Description
Price

1

CABLE, THROTTLE 1

8FP-26311-00-00

$54.51

2

GRIP

8GF-26241-00-00

$23.83

3

GRIP,WARMER

8GL-2626A-00-00

$90.09

4

GRIP,WARMER

8GL-2626A-10-00

$87.89

5

RIVET (856)

90267-48014-00

$3.11

6

COVER, HANDLEBAR LOWER 1

8FP-26144-00-00

$62.32

7

DAMPER

8FP-26113-00-00

$1.58

8

COVER, HANDLEBAR LOWER 2

8FP-26146-00-00

$48.20

9

SCREW, BINDING(1UY)

90154-05041-00

$6.68

10

TUBE, CORD

8FP-82351-00-00

$9.66

11

GUARD, BRUSH 1

8GL-F6141-20-00

Unavailable

12

GUARD, BRUSH 2

8GL-F6142-20-00

Unavailable

13

BRACKET 3

8GL-2612L-01-00

$58.91

14

BRACKET 4

8GL-2612M-01-00

$62.72

15

BRKT 2

8GL-2612K-00-00

$17.17

16

BOLT(3XP)

90109-065F3-00

$6.74

17

BOLT

91312-05030-00

$2.92
