Description

Price

1

STEERING GATE COMP.

8HG-23870-02-00

Unavailable

2

STOPPER

8HG-23376-00-00

$11.49

3

STOPPER

8FA-24768-00-00

Unavailable

4

WASHER, PLATE

90201-10032-00

$1.17

5

COVER, MOTOR

8HG-238B6-01-00

$30.99

6

BOLT, WITH HOLE

90102-08007-00

Unavailable

7

BOLT(3KJ)

90109-063F1-00

$2.97

8

BRACKET

JT1-83614-00-00

$28.99

9

SCREW, BIND (705)

98980-06016-00

$8.49

10

WASHER, PLATE(49E)

90201-087H6-00

$2.39

11

NUT,FLANGE(J10)

95702-08500-00

$1.43

12

BOLT, FLANGE

90105-08236-00

$3.55

13

WASHER (853)

90201-08326-00

$8.49

14

BOLT, FLANGE(6TA)

95817-08030-00

$8.49

15

LATCH

8FA-2389E-00-00

$13.49

16

NUT, SELF-LOCKING

95602-08200-00

Unavailable

17

CLAMP

90462-10022-00

Unavailable

18

CLIP 136253750000

90468-12006-00

Unavailable

Yamaha RX10PXTAR (APEX XTX) 8HN10 2011 STEERING GATE Diagram

STEERING GATE COMP.

STOPPER

STOPPER

WASHER, PLATE

COVER, MOTOR

BOLT, WITH HOLE

BOLT(3KJ)

BRACKET

SCREW, BIND (705)

WASHER, PLATE(49E)

NUT,FLANGE(J10)

BOLT, FLANGE

WASHER (853)

BOLT, FLANGE(6TA)

LATCH

NUT, SELF-LOCKING

CLAMP

CLIP 136253750000
