Yamaha RX10ML (APEX MOUNTAIN) 8FS1 2006 BUMPER Diagram
#
1
BUMPER, FRONT 1
8FA-77511-01-00
$250.99
2
BOLT, FLANGE(JN5)
95817-08016-00
$5.49
3
BUMPER, REAR 1
8FS-77541-00-00
Unavailable
4
BOLT, FLANGE(8AB)
95817-08020-00
$9.49
5
FLAP
8GT-K7595-00-00
Unavailable
6
RIVET, BLIND
90267-47200-00
$2.75
7
PROTECTOR 1
8FP-77551-01-P0
Unavailable
7
PROTECTOR 1
8FP-77551-01-P1
$116.99
8
LINING, SHROUD 1
8FP-77261-00-00
Unavailable
9
PROTECTOR 2
8FP-77552-01-P0
Unavailable
9
PROTECTOR 2
8FP-77552-01-P1
Unavailable
10
LINING, SHROUD 2
8FP-77262-00-00
Unavailable
11
LINING, SHROUD 3
8FP-77263-00-00
$4.46
12
SCREW, BINDING
90154-06009-00
$4.61
13
COVER, TAILLIGHT
8FS-84516-00-00
Unavailable
14
LOUVER 1
8FS-77441-00-00
Unavailable
15
SCREW, TAPPING(4MV)
97707-50016-00
Unavailable
16
CAP
8FS-77517-00-00
Unavailable
17
BOLT,SOCKET HEAD
91314-06020-00
Unavailable
18
YBS66-6 WASHER, PLAIN
92990-06200-00
Unavailable
19
NUT, HEXAGON
95380-06600-00
Unavailable
20
BRACKET, REAR (L.H)
8FS-77533-00-00
Unavailable
21
SCREW, BINDING
90154-06009-00
$4.61
22
NUT,SELF-LOCKING
95607-06200-00
Unavailable
23
PROTECTOR 6
8FS-77556-00-00
Unavailable
24
PROTECTOR 7
8FS-77557-00-00
Unavailable
25
RIVET
90269-06081-00
Unavailable
26
EMBLEM, YAMAHA
99244-00140-00
Unavailable
27
COVER, TAIL 1
8FS-2471K-00-00
Unavailable
28
STAY, REAR
8FS-24716-00-00
Unavailable
29
COVER, TAIL 2
8FS-2472K-00-00
Unavailable
30
STAY, LH.
8FS-2474R-00-00
Unavailable
31
STAY, RH.
8FS-2474T-00-00
Unavailable
32
COVER, TAIL
8FS-24756-00-00
Unavailable
33
PLUG
90338-44019-00
Unavailable
34
COVER
8FS-24796-00-00
Unavailable
35
COVER,2
8FS-2475X-00-00
Unavailable
36
SCREW, BINDING
90154-06009-00
$4.61
37
BOLT, FLANGE(JN5)
95817-08045-00
Unavailable
38
BOLT, FLANGE
95817-08055-00
Unavailable
39
NUT, SELF-LOCKING
90185-08169-00
Unavailable
40
COLLAR
90387-08079-00
Unavailable
41
SCREW, TAPPING(4TV)
90167-05077-00
Unavailable
42
SCREW, TAPPING(4TV)
90167-05078-00
Unavailable
43
PLATE, COVER
8FS-2471P-00-00
Unavailable
44
RIVET
90269-06081-00
Unavailable
45
EMBLEM
8ET-24897-00-00
Unavailable
46
LABEL 1
8FS-24875-E0-00
Unavailable
