Yamaha RX10GTZL (APEX GT) 8GDA 2010 INTAKE 2 Diagram
#
1
THROTTLE BODY ASSY
8FP-13750-10-00
Unavailable
2
PIPE
8FP-13938-00-00
Unavailable
3
GASKET, MANIFOLD
8FP-13556-00-00
$13.99
4
INJECTOR
8FP-13761-10-00
Unavailable
5
HOSE
8FP-14987-00-00
Unavailable
6
GASKET, EXHAUST
98507-05008-00
$3.55
7
HOSE
8FP-14987-10-00
Unavailable
8
PIPE
8FP-14396-00-00
Unavailable
9
HOSE
8FP-14987-20-00
Unavailable
10
HOSE
8FP-14987-30-00
Unavailable
11
THROTTLE SCREW SET
5JW-14103-10-00
Unavailable
12
CLIP, PIPE
8A7-14139-00-00
$8.99
13
CAP
895-14169-00-00
$5.49
14
REGULATOR, PRESSURE
8FP-13906-00-00
Unavailable
15
SCREW, PAN
98507-06010-00
$3.55
16
. PIPE 1
8FP-14348-00-00
Unavailable
17
PIPE 1
8FP-14348-10-00
Unavailable
18
SENSOR, PRESSURE
5PS-82380-00-00
Unavailable
19
SCREW, PAN
98517-06012-00
Unavailable
20
CLIP
90467-11028-00
Unavailable
21
SCREW
8CC-14216-10-00
Unavailable
22
THROTTLE SENSOR AS
8GL-85885-01-00
Unavailable
23
CLIP
4KM-14137-00-00
Unavailable
24
EXTENSION, WIRE HARNESS
8FP-82386-01-00
Unavailable
25
PIPE 1
5JW-14348-00-00
Unavailable
26
PIPE
8FP-14349-00-00
Unavailable
27
HOSE
5PS-14987-00-00
Unavailable
28
PIPE
8FP-14349-10-00
Unavailable
29
CONNECTOR
5PW-1410F-00-00
Unavailable
30
PIPE
8FP-14349-20-00
Unavailable
31
HOSE
5JW-14987-00-00
Unavailable
32
. PIPE, JOINT 1
68V-24376-00-00
Unavailable
33
PIPE 1
5FL-14348-10-00
Unavailable
34
PIPE
8FP-14349-30-00
Unavailable
35
AIR SCREW SET
5JW-14104-00-00
Unavailable
36
O-RING, PILOT SCREW
3H1-14147-00-00
Unavailable
37
. PIPE
8FP-14148-00-00
Unavailable
38
JOINT
8FP-14454-00-00
Unavailable
39
CLIP (21V)
90467-22080-00
Unavailable
40
PIPE
8FP-14149-00-00
Unavailable
41
ADJUST SCREW SET
8FP-14503-00-00
Unavailable
42
CLIP
8FP-13577-00-00
Unavailable
43
CLIP
8FP-14137-00-00
Unavailable
