Partiron

Sea-doo RX, 5579/5580/5581/5582, 2002 Oil Injection System Diagram

#

Description
Price

1

Was 293550004 Dielectric Grease, 150 g

219704453

$38.99

2

FILLER NECK - Call your local BRP dealership

275000242

Unavailable

3

Gasket

293250132

Unavailable

4

Nut-Neck Oil Filler

211100013

Unavailable

5

Oil Cap

275000186

Unavailable

6

O-RING - Call your local BRP dealership

293250025

Unavailable

7

Oil Cap Chain

275500015

Unavailable

8

Pop Rivet 1/8"

390407900

$1.49

9

Flat Washer M3, Stainless

234032600

$0.55

10

Oil Tank

275000238

$98.99

11

OIL 2T CARB PREM. MINERAL QT/0,946L This part replaces 413802900.

779119

$12.99

2T Snowmobile Premium Mineral Oil This part replaces 413803000.

779120

$43.99

OIL 2T CARB PREM. MINERAL 55 GAL/205L This part replaces 413803200.

779123

Unavailable

SYNTHETIC INJECTION OIL, 12 X 1 LITER - Call your local BRP dealership

413710500

Unavailable

OIL 2T 3X1G SYNTH - Call your local BRP dealership This part replaces 293600046.

293600133

Unavailable

OIL 2T E-TEC SYNTHETIC 55 GAL/205L This part replaces 293600047.

779130

Unavailable

12

Grommet

293720008

$14.75

13

Elbow Fitting 90°

293710070

Unavailable

14

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

$32.99

15

Tie Wrap 94 mm | 4X4

293750001

$1.03

16

Tie Wrap 142 mm

293750002

$1.25

17

OIL FILTER - Call your local BRP dealership

275000051

Unavailable

18

Oetiker Clamp

293650042

$3.09

19

Check Valve

275500398

$10.99

20

HOSE-6MM. 5000MM LONG - Call your local BRP dealership

219704396

Unavailable

21

Oil Sensor | Includes 44 to 48

278001402

Unavailable

22

Wire Seal

278000218

$4.39

23

Male Terminal | XT Models

278000222

$3.19

24

Female Housing, 2 Circuits

278000217

$9.59

25

Grommet

293720008

$14.75

26

Filler Hose

275000188

Unavailable

27

Tridon Clamp

293650035

$7.29
