Description

Price

1

REED VALVE ASSY

345-13610-20-00

$228.99

2

REED, VALVE

345-13613-70-00

$72.99

3

. STOPPER, REED VALVE

345-13616-70-00

Unavailable

4

SCREW, PAN HEAD (J10)

98580-03008-00

$3.55

5

GASKET, VALVE SEAT

15F-E3622-00-00

Unavailable

6

JOINT, CARBURETOR

5L9-E3565-00-00

Unavailable

7

CLAMP, HOSE (5H0)

90460-43179-00

$19.99

8

BOLT,W/WASHER

97502-06525-09

Unavailable

9

CLAMP SPECIAL SHAPE

90465-20800-09

Unavailable

10

CHAMBER, AIR

5L9-E3581-00-00

Unavailable

11

PIPE, INTAKE MANIFOLD

5L9-E3584-00-00

Unavailable

12

GROMMET 839774310000

90480-14023-00

$7.49

13

SCREW, PAN HEAD WITH WASHER

97602-06125-09

Unavailable

14

COLLAR

90387-06158-00

$8.49

15

PIPE

5L9-E4465-01-00

Unavailable

16

SPRING, COMPRESSION

90501-20802-09

Unavailable

17

CLAMP,HOSE

90460-16W00-00

Unavailable

18

CLAMP,HOSE

90460-16W00-00

Unavailable

Yamaha RT180A (RT180) 1990 AIR FILTER Diagram

REED VALVE ASSY

REED, VALVE

. STOPPER, REED VALVE

SCREW, PAN HEAD (J10)

GASKET, VALVE SEAT

JOINT, CARBURETOR

CLAMP, HOSE (5H0)

BOLT,W/WASHER

CLAMP SPECIAL SHAPE

CHAMBER, AIR

PIPE, INTAKE MANIFOLD

GROMMET 839774310000

SCREW, PAN HEAD WITH WASHER

COLLAR

PIPE

SPRING, COMPRESSION

CLAMP,HOSE

CLAMP,HOSE
