Yamaha RST90PGTER (RS VENTURE GT) 8HX50 2014 INSTRUMENT PANEL Diagram

#

Description
Price

1

PANEL, INSTRUMENT

8FP-77711-00-PB

$419.56

2

GROMMET

8FP-77746-01-00

$15.71

3

PLATE, SPRING

4XV-2177L-01-00

$5.79

4

SCREW, BINDING

90154-06009-00

$2.80

5

BOLT

90109-06220-00

$6.94

6

PLATE, SPRING

5PW-2177L-01-00

$5.80

7

PANEL, INSTRUMENT

8HF-77712-00-P5

Unavailable

8

DAMPER 1

8HF-77319-00-00

Unavailable

9

HEAD

5PW-28386-00-00

$14.07

10

WASHER, SPECIAL 1

8HW-21757-00-00

$0.41

11

COVER, SIDE 1

8FP-21711-00-00

Unavailable

12

COVER, SIDE 2

8FP-21721-00-00

Unavailable

13

TAPE 2

8FR-7717F-00-00

$3.61

14

PAD 1

8FR-77151-00-00

$3.97

15

SCREW

90149-06117-00

$5.03

16

SCREW, BINDING

90154-06009-00

$2.80
