Yamaha RST90GTYS (RS VENTURE GT) 8HF10 2009 INSTRUMENT PANEL Diagram

#

Description
Price

1

PANEL, INSTRUMENT

8FP-77711-00-P1

$330.99

2

GROMMET

8FP-77746-01-00

$17.99

3

PLATE, SPRING

4XV-2177L-01-00

$6.99

4

SCREW, BINDING

90154-06009-00

$4.61

5

BOLT

90109-06220-00

$10.49

6

PLATE, SPRING

5PW-2177L-01-00

$6.99

7

PANEL, INSTRUMENT

8HF-77712-00-P1

Unavailable

8

HEAD

5PW-28386-00-00

$17.49

9

WASHER, SPECIAL 1

2TK-21757-00-00

$3.38

10

COVER, SIDE 1

8FP-21711-00-00

Unavailable

11

COVER, SIDE 2

8FP-21721-00-00

Unavailable

12

TAPE 2

8FR-7717F-00-00

$3.88

13

PAD 1

8FR-77151-00-00

$3.18

14

SCREW(2XF)

90149-06263-00

$9.49

15

SCREW, BINDING

90154-06009-00

$4.61
