Description

Price

1

TAILLIGHT UNIT ASSY

5JJ-84710-12-00

$220.99

2

BULB

1A2-84714-50-00

$14.49

3

CORD ASSY

5JJ-84755-00-00

Unavailable

4

DAMPER

4XV-83513-00-00

$7.99

5

SCREW, TAPPING(4MV)

97707-50016-00

$2.19

6

WASHER, PLATE (8J0)

90201-05725-00

Unavailable

7

DAMPER

5JJ-21747-00-00

Unavailable

8

GROMMET (509)

90480-18171-00

$8.49

9

BRACKET, TAILLIGHT

8FA-2117E-00-00

Unavailable

10

BRACKET, FRONT

8ES-77531-00-00

Unavailable

11

BRACKET, FRONT (R.H)

8ES-77532-00-00

Unavailable

12

NUT, SPRING(4ES)

90183-06069-00

Unavailable

13

BOLT, FLANGE

95817-06014-00

Unavailable

14

NUT,SELF-LOCKING

95607-06200-00

$12.49

Yamaha RSG90W (RAGE) 8FL5 2007 TAILLIGHT Diagram

TAILLIGHT UNIT ASSY

BULB

CORD ASSY

DAMPER

SCREW, TAPPING(4MV)

WASHER, PLATE (8J0)

DAMPER

GROMMET (509)

BRACKET, TAILLIGHT

BRACKET, FRONT

BRACKET, FRONT (R.H)

NUT, SPRING(4ES)

BOLT, FLANGE

NUT,SELF-LOCKING
