2006 Yamaha Vector Er (RS90RL) Instrument Panel Diagram

← All diagrams

Find the part on the Instrument Panel diagram for your 2006 Yamaha Vector Er (RS90RL), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2006 Yamaha Vector Er (RS90RL) Instrument Panel Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

PANEL, INSTRUMENT (DEEP PURPLISH BLUE METALLIC C)

8FA-77711-00-P1

1
Out of stock

1

PANEL, INSTRUMENT (SILVER METALLIC 1)

8FA-77711-00-P5

1
Out of stock

1

PANEL, INSTRUMENT (YAMAHA BLACK)

8FA-77711-20-33

1
Out of stock

1

PANEL, INSTRUMENT (DEEP PURPLISH BLUE METALLIC C)

8FA-77711-20-P2

1
Out of stock

2

GROMMET

8FA-77746-00-00

—

$6.31

In stock

3

STOPPER, MAIN STAND

4N0-27114-00-00

1
Out of stock

4

LOUVER 1

8FA-77131-00-00

—

$30.68

In stock

5

LOUVER 2

8FA-77132-00-00

1

$30.68

In stock

6

SCREW, BINDING

90154-06009-00

1

$2.92

In stock

7

SCREW(2XF)

90149-06263-00

1
Out of stock

8

NUT, SPRING

90183-06100-00

1
Out of stock

9

BODY, LATCH 1

8FA-77171-00-00

1

$12.03

In stock

10

GROMMET (4H7)

90480-16278-00

1

$2.62

In stock

11

EMBLEM

5JW-2413B-00-00

—
Out of stock

12

TRIM, INSTRUMENT PANEL 1

8FA-77737-00-00

—

$0.34

In stock
