Yamaha RS90LTGTZW (RS VECTOR LTX GT) 8JB10 2010 CAMSHAFT CHAIN Diagram

#

Description
Price

1

CAMSHAFT ASSY 1

8HF-12170-00-00

Unavailable

2

CAMSHAFT ASSY 2

8HF-12180-00-00

Unavailable

3

SPROCKET, CAM CHAIN

8GL-12176-00-00

Unavailable

4

BOLT, FLANGE

90105-07004-00

$4.66

5

CHAIN

94591-57140-00

$33.34

6

TENSIONER ASSY, CAM CHAIN

8GL-12210-10-00

$173.11

7

GASKET, TENSIONER CASE

2C0-12213-00-00

$6.29

8

BOLT, HEXAGON SOCKET HEAD

90110-06106-00

$5.90

9

DAMPER, CHAIN 1

8GL-12251-01-00

$23.06

10

DAMPER, CHAIN 2

8GL-12252-01-00

Unavailable

11

BOLT

90109-06188-00

$4.64
