Suzuki RM80S (1995) RIGHT HANDLE SWITCH (MODEL G/H/J) Diagram

#

Description
Price

1

GRIP, THROTTLE This part replaces 57110-14300.

57110-27C00

$24.14

2

ROTOR, THROTTLE

57114-20410

$6.80

3

CASE ASSY, THROTTLE | Includes Item(s) 4 - 7

57100-20411

Unavailable

4

GUIDE PIECE

57122-20410

$7.22

5

COVER

57129-20411

$13.50

6

SCREW This part replaces 02132-04105.

02122-0410A

$1.22

7

SCREW This part replaces 02112-05168.

02112-05167

$1.97

8

LEVER, BRAKE

57421-14502

Unavailable

9

BOLT, BRAKE LEVER

57431-14500

$5.75

10

NUT This part replaces 57442-14500.

08316-1006B

$2.50

11

BOLT, ADJUST

57431-14511

$5.46

12

NUT This part replaces 08310-11057.

08310-00057

$1.83

13

SPRING, RETURN

57318-14502

$4.09

14

COVER, BRAKE LEVER

57341-14501

$10.58

15

COVER, THROTTLE CASE

57129-14501

Unavailable

16

REFER TO FIG.29A(G- 5) FOR

SPECIAL NOTE

Unavailable
