Suzuki RM65 (2005) GENERATOR Diagram

#

Description

Price

21003

STATOR

K2100-31361

Unavailable

21007

ROTOR

K2100-71364

Unavailable

21119

IGNITER

K2111-91551

Unavailable

92015

NUT,FLANGED,10MM

KK920-15077

Unavailable

92037

CLAMP,L=60

K9203-71069

Unavailable

92037A

CLAMP

K9203-71173

Unavailable

92038

KEY,WOODRUFF

KK920-38001

Unavailable

92072

BAND,L=140

K9207-21293

Unavailable

92150

BOLT,6X12

K9215-01435

$3.40

92150A

BOLT-FLANGED-SM This part replaces K9215-01599.

K132B-A0612

$1.49

224

SCREW-PAN-WS-CR This part replaces KK224-B0514.

K224A-A0514

Unavailable
