Suzuki RM250 (2006) FRONT FENDER (MODEL K4/K5/K6) Diagram

#

Description

Price

1

FENDER, FRONT (YELLOW)

53111-37F01-YU1

$48.30

2

EMBLEM, "S" | MODEL K4

68151-08G00-NN3

$12.35

2

EMBLEM, "S" | MODEL K5

68151-37F00-AZT

$27.40

2

EMBLEM,"S" | MODEL K6 This part replaces 68151-37F10-CFM.

68151-37F11-CFM

$27.40

3

BOLT This part replaces 01547-06163.

01547-0616B

$2.45

4

WASHER, LOWER

09160-06136

$1.84

5

WASHER

09169-06078

$3.55

6

WASHER, FRONT NUMBER (WHITE) | MODEL K4/K5 This part replaces 94911-37F00-30H.

94911-37F02-30H

$71.38

6

WASHER, FRONT NUMBER (WHITE) | MODEL K6 This part replaces 94911-37F01-30H.

94911-37F02-30H

$71.38

7

EMBLEM, "SUZUKI" | MODEL K4

68171-44B00-8YM

$12.48

8

BOLT

09103-06233

$2.11
