Suzuki RM250 (2006) FRONT DAMPER (MODEL K3) Diagram

#

Description
Price

1

DAMPER ASSY, FRONT FORK RH | E3

51103-37F50

Unavailable

1

DAMPER ASSY, FRONT FORK RH | E28

51103-37F40

Unavailable

2

DAMPER ASSY, FRONT FORK LH | E3

51104-37F50

Unavailable

2

DAMPER ASSY, FRONT FORK LH | E28; Includes Item(s) 3 - 26

51104-37F40

Unavailable

3

TUBE, INNER RH

51110-37F40

Unavailable

4

TUBE, INNER LH

51120-37F40

Unavailable

5

BUSH, SLIDE

51121-37F00

$32.17

6

BUSH, GUIDE

51167-37F40

Unavailable

7

SPACER, SEAL

51158-27C00

$6.19

8

SEAL, OIL

51153-37F00

$38.38

9

RING, OIL SEAL STOPPER

51156-27C00

$5.98

10

SEAL, DUST

51173-37F00

Unavailable

11

TUBE, OUTER

51130-37F40

Unavailable

12

SPRING, FRONT (K=4.2) | E3

51171-37F70

Unavailable

12

SPRING, FRONT (K=4.3) | E28

51171-37F80

Unavailable

13

VALVE ASSY, BASE | E3

51170-37F50

Unavailable

13

VALVE ASSY, BASE | E28

51170-37F40

Unavailable

14

O RING

51174-37F40

Unavailable

15

O RING

51177-37F40

Unavailable

16

PACKING

51148-37F00

Unavailable

17

CAP, RUBBER

51189-28C00

Unavailable

18

SPACER

51198-37F40

Unavailable

19

ROD ASSY, PISTON | E3

51128-37F50

Unavailable

19

ROD ASSY, PISTON | E28

51128-37F40

Unavailable

20

NUT

51814-37F40

Unavailable

21

GUIDE, SPRING

51172-37F40

Unavailable

22

CAP

51351-37F40

Unavailable

23

O RING

51117-37F40

Unavailable

24

WASHER

51197-37F40

Unavailable

25

RUBBER, CUSHION

51196-37F40

Unavailable

26

BOLT This part replaces 51321-37F00.

51451-10G00

$5.11

27

GUIDE, PROTECTOR RH

51220-37F00

Unavailable

28

GUIDE, PROTECTOR LH

51210-37F00

$62.07

29

BOLT

01547-06257

$2.03

30

PROTECTOR, RH

51501-36E60

Unavailable

31

PROTECTOR, LH

51511-36E60

Unavailable

32

BOLT

09103-06256

$2.28

33

SPRING, FRONT (SOFT,K=4.2) | E28 OPT

51171-37F70

Unavailable

33

SPRING, FRONT (HARD,K=4.4) | E3/E28 OPT

51171-37FA0

Unavailable

33

SPRING, FRONT (HARD,K=4.5) | E28 OPT

51171-37FB0

Unavailable

33

SPRING, FRONT (HARD,K=4.3) | E3 OPT

51171-37F80

Unavailable

33

SPRING, FRONT (SOFT,K=4.1) | E3 OPT

51171-37F90

Unavailable
