Suzuki RM250 (2006) ELECTRICAL (MODEL K5/K6) Diagram

#

Description
Price

1

HARNESS, WIRING

36610-37F30

$181.83

2

CLAMP

36651-48E00

$3.25

3

CLAMP (L:90)

09407-11402

$1.80

4

CLAMP (L:45)

09404-06429

$1.83

5

CDI, UNIT | MODEL K5

32900-37F40

Unavailable

5

CDI, UNIT | MODEL K6

32900-37F50

Unavailable

6

CUSHION CDI

32980-37F00

$11.18

7

COIL ASSY, IGNITION

33410-37F00

$127.20

8

BOLT, IGNITION (6X16)

09103-06234

$2.35

9

CAP, SPARK PLUG

33510-20A02

$24.39

10

SWITCH ASSY,ENGINE STOP | Includes Item(s) 11

37820-36E00

$25.46

11

SCREW

02112-33165

$1.49

12

CLAMP, ENGINE STOP (L:128) | MODEL K5

09407-12402

$3.04

13

CLAMP (L:95) | MODEL K6

09407-11401

$2.63

13

CLAMP (L:125) | MODEL K6

09407-14403

$2.26
