Suzuki RM250 (2006) CYLINDER (MODEL K3/K4/K5/K6) Diagram

#

Description
Price

1

HEAD, CYLINDER | MODEL K3 This part replaces 11111-37F21.

11111-37F40

$263.12

1

HEAD, CYLINDER | MODEL K4 This part replaces 11111-37F30.

11111-37F40

$263.12

1

HEAD, CYLINDER | MODEL K5/K6

11111-37F40

$263.12

1A

PIN (4X13.8) | MODEL K5/K6

04221-04089

$1.49

2

O RING, CYLINDER HEAD NO.1

11147-37F00

$16.55

3

O RING, CYLINDER HEAD NO.2

11148-37F00

$8.67

4

NUT

09159-08049

$4.71

5

WASHER

09168-08021

$2.61

6

STUD BOLT (8X38) This part replaces 09108-08227.

09108-08231

$3.42

7

SPARK PLUG (NGK,BR8EG)

09482-00561

$14.55

8

CYLINDER SET | MODEL K3

11200-37882

Unavailable

8

CYLINDER SET | MODEL K4 This part replaces 11200-37890.

11201-37840

Unavailable

8

CYLINDER SET | MODEL K5

11201-37840

Unavailable

8

CYLINDER SET | MODEL K6; Includes Item(s) 9

11201-37850

Unavailable

9

UNION, CYLINDER

16910-09401

$18.20

10

GASKET, CYLINDER

11241-37F20

$10.62

11

STUD BOLT (L:30) This part replaces 01421-10308.

01421-1030A

$2.57

12

STUD BOLT (L:40) This part replaces 01421-10408.

01421-1040A

$2.62

13

STUD BOLT (L:50) This part replaces 01421-10503.

01421-1050A

$3.72

14

STUD BOLT (L:55)

09108-10141

$4.35

15

PIN

09206-13017

$7.61

16

NUT

09159-10108

$2.93

17

COVER, CYLINDER NO.1

11231-37F20

$43.27

18

GASKET, CYLINDER COVER NO.1

11233-37F20

$8.07

19

BOLT (5X16) This part replaces 09103-05023.

09103-05016

$1.93

20

COVER, CYLINDER NO.2

11248-37F20

$51.32

21

GASKET, CYLINDER COVER NO.2

11238-37F20

$4.52

22

BOLT (5X16) This part replaces 09103-05023.

09103-05016

$1.93

23

HOSE,5X10X600 | L:600!390 This part replaces 09352-50823-600.

44421-13ER0

$10.06

23A

HOSE,5X10X600 | L:600!360 This part replaces 09352-50823-600.

44421-13ER0

$10.06

24

COVER, CYLINDER NO.3

11249-37F20

$29.33

25

GASKET, CYLINDER COVER NO.3

11234-37F20

$5.87

26

BOLT (5X16) This part replaces 09103-05023.

09103-05016

$1.93

27

BOLT (10X48) | MODEL K3/K4

09103-10126

$4.50

27

BOLT (10X48) | MODEL K5/K6

09103-10149

$3.70

28

NUT

09159-10078

$2.96

29

SCREW, EXHAUST VALVE DRAIN

11252-37F20

$5.77
