Suzuki RM250 (2006) CRANKSHAFT (MODEL K1/K2) Diagram

#

Description
Price

1

PISTON | MODEL K1 This part replaces 12110-37E40-0F0.

12110-37E42-0F0

$127.83

1

PISTON | MODEL K2

12110-37E42-0F0

$127.83

2

RING, PISTON

12141-37E02

Unavailable

3

PIN, PISTON | MODEL K1 This part replaces 12151-28C00.

12151-37F00

$14.15

3

PIN, PISTON | MODEL K2

12151-37F00

$14.15

4

CIRCLIP

09381-18002

$1.67

5

BEARING (18X23X22)

09263-18016

$19.93

6

CRANKSHAFT ASSY | MODEL K1

12200-37E31

Unavailable

6

CRANKSHAFT ASSY | MODEL K2; Includes Item(s) 7 - 12

12200-37F00

Unavailable

7

ROD, CONNECTING

12161-37E00

$154.37

8

WASHER

09160-24027

$23.13

9

PIN, CRANK

12211-05D00

$43.33

10

BEARING (24X30X20)

09263-24026

$69.90

11

CRANKSHAFT, RH | MODEL K1

12220-37E31

Unavailable

11

CRANKSHAFT, RH | MODEL K2

12220-37F00

Unavailable

12

CRANKSHAFT, LH | MODEL K1

12260-37E31

Unavailable

12

CRANKSHAFT, LH | MODEL K2

12260-37F00

Unavailable

13

BEARING (28X68X18)

09262-28027

$71.59

14

OIL SEAL, RH (38X52X8)

09283-38021

$20.01

15

OIL SEAL, LH (25X37X6)

09283-25099

$12.96

16

GEAR, PRIMARY DRIVE (NT:21)

21111-37F00

Unavailable

17

BOLT, PRIMARY DRIVE GEAR | MODEL K1 This part replaces 21141-27C11.

09103-10339

$9.32

17

BOLT, PRIMARY DRIVE GEAR | MODEL K2

09103-10339

$9.32

18

WASHER

09164-11004

$5.47

19

TOP END KIT, ENGINE | OPT E3; Includes Item(s) 19 - 19

12102-37812

Unavailable

19

O RING, CYLINDER HEAD NO.1 | NOT SHOWN

11147-37F00

$16.55

19

O RING, CYLINDER HEAD NO.2 | NOT SHOWN

11148-37F00

$8.67

19

GASKET, CYLINDER | NOT SHOWN

11241-37F01

Unavailable

19

PISTON | NOT SHOWN

12110-37E42-0F0

$127.83

19

RING, PISTON | NOT SHOWN

12141-37E02

Unavailable

19

CIRCLIP | NOT SHOWN

09381-18002

$1.67

20

PISTON KIT | OPT MODEL K1 E28 This part replaces 12101-37890.

12101-37893

$203.00

20

PISTON KIT | OPT MODEL K2 E28; Includes Item(s) 20 - 20

12101-37893

$203.00

20

PISTON | NOT SHOWN

12110-37E42-0F0

$127.83

20

RING, PISTON | NOT SHOWN

12141-37E02

Unavailable

20

PIN, PISTON | MODEL K1 NOT SHOWN This part replaces 12151-28C00.

12151-37F00

$14.15

20

PIN, PISTON | MODEL K2 NOT SHOWN

12151-37F00

$14.15

20

BEARING | NOT SHOWN

09263-18016

$19.93

20

CIRCLIP | NOT SHOWN

09381-18002

$1.67
