Suzuki RM250 (2006) CLUTCH (MODEL K3/K4/K5) Diagram

#

Description
Price

1

GEAR ASSY, PRIMARY DRIVEN | NT:63/21 This part replaces 21200-37E03.

21200-37F10

$388.57

2

SPACER, PRIMARY DRIVEN GEAR This part replaces 21251-37E00.

21251-37E01

$50.70

3

BEARING, PRIMARY DRIVEN | 29X34X27

09263-29009

$21.10

4

HUB SET,CLUTCH | MODEL K3 This part replaces 21410-37E11.

21410-37810

Unavailable

4

HUB, CLUTCH SLEEVE | MODEL K4

21410-37E20

$151.28

4

HUB, CLUTCH SLEEVE | MODEL K5

21410-37F40

Unavailable

5

PLATE, CLUTCH DRIVE NO.1

21441-37F20

$21.16

6

PLATE,CLUTCH DRIVE NO.2 (T:2.

21441-37F30

$13.53

7

PLATE, CLUTCH DRIVEN

21451-37F00

$9.24

8

DISK, CLUTCH PRESSURE

21462-37F20

$68.92

9

BOLT, CLUTCH (5X25)

09116-05019

$2.32

10

NUT, CLUTCH SLEEVE HUB

09140-18013

$12.00

11

WASHER, CLUTCH HUB THR | MODEL K3,22X38X2

09160-22067

$10.08

11

WASHER, CLUTCH HUB THR | MODEL K4/K5,22X38X3

09160-22080

Unavailable

12

WASHER, CLUTCH HUB | MODEL K3/K4,22X42X0.8

09167-22021

$1.78

12

WASHER, CLUTCH HUB | MODEL K5,22X42X0.8

09167-22026

Unavailable

13

SPRING, CLUTCH

09440-18030

$6.51

14

ROD, CLUTCH PUSH

23110-37F00

$18.15

15

PIECE,CLUTCH PUSH

23121-37F00

$20.21

16

CAMSHAFT, CLUTCH RELEASE

23200-37E02

$67.73

17

BEARING, CLUTCH RELEASE | 10.1X22X2.8

09263-10002

$10.19

18

BEARING, NO.2 | 12X16X10

09263-12024

$12.67

19

SEAL, CL RELEASE CAMSHAFT | 12X19X5

09285-12004

$6.24
