Description

Price

1

CRANKCASE SET | Includes Item(s) 2 - 7

11301-36840

$1,105.08

2

GASKET, CRANKCASE

11481-36F30

$21.42

3

PIN (10.4X13X20)

09206-13017

$7.61

4

BOLT (6X40)

09103-06241

$3.08

5

BOLT (6X45)

09103-06242

$2.76

6

BOLT (6X50)

09103-06244

$2.76

7

BOLT (6X55)

09103-06243

$3.08

8

BOLT (10X90)

09103-10374

$6.20

9

BOLT (10X130)

09103-10122

$8.38

10

NUT

09159-10078

$2.96

11

PLUG, DRAIN

09247-12012

$6.88

12

GASKET

09168-12002

$1.59

13

VALVE ASSY, REED | Includes Item(s) 14 - 16

13150-36F00

Unavailable

14

STOPPER,REED VA This part replaces 13152-43D00.

13152-43D01

$7.18

15

VALVE,REED This part replaces 13153-43D10.

13153-43D11

$50.22

16

SCREW This part replaces 02112-33083.

02112-3308A

$2.23

17

BOLT

01547-06207

$2.01

18

PIPE,INTAKE This part replaces 13110-36F30.

13110-36F31

$68.17

19

CLAMP

09402-56901

$5.36

Suzuki RM125 (2008) CRANKCASE Diagram
