Suzuki RM125 (2006) EXHAUST VALVE (MODEL K4/K5/K6) Diagram

#

Description
Price

1

VALVE ASSY, EXHAUST MAIN | MODEL K4

11250-36F30

Unavailable

1

VALVE ASSY, EXHAUST MAIN | MODEL K5/K6

11250-36F40

$468.55

2

BOLT This part replaces 07130-05123.

07130-0512B

$2.53

3

BOLT, EXHAUST VALVE

09103-05022

$2.27

4

VALVE, EXHAUST SIDE, R | MODEL K4

11255-36F30

$98.79

4

VALVE, EXHAUST SIDE, R | MODEL K5/K6

11255-36F40

$99.60

5

VALVE, EXHAUST SIDE, L | MODEL K4

11256-36F30

$98.79

5

VALVE, EXHAUST SIDE, L | MODEL K5/K6

11256-36F40

$99.60

6

SHAFT, EXHAUST SIDE VALVE

11260-36F30

$22.72

7

SPRING, EXHAUST VALVE

11257-36F11

$8.55

8

SHAFT, EXHAUST VALVE

11259-36F30

Unavailable

9

BOLT, EXHAUST VALVE SHAFT

09106-04003

$1.94

10

ARM, EXHAUST VALVE SHAFT

11264-36F30

$84.10

11

BOLT, EXHAUST VALVE SHAFT STOP

09103-06256

$2.27

12

RETAINER, EXHAUST VALVE SHAFT STOP

24741-21A00

$2.80

13

WASHER, GOVERNOR THRUST

09181-15223

$2.55

14

PIN, GOVERNOR SHAFT

09261-03017

$2.67

15

BEARING, GOVERNOR THRUST

09263-15003

$7.49

16

BALL, GOVERNOR

06111-12004

$1.95

17

SCREW, ACTUATOR BASE

09120-05003

$1.76

18

BEARING, GOVERNOR SHAFT

09262-08005

$11.44

19

ACTUATOR, EXHAUST

12689-36F30

Unavailable

20

BOLT, ACTUATOR ARM

09106-04003

$1.94

21

BASE, ACTUATOR

12681-03B00

$203.48

22

ARM, ACTUATOR

12682-36F21

$10.78

23

GOVERNOR, DRIVEN

12672-36F10

$43.50

24

STOPPER, GOVERNOR SPRING

12674-36F10

$31.90

25

STOPPER, GOVERNOR SPRING

12675-36F11

$23.73

26

SPACER, GOVERNOR

12676-36F10

$19.97

27

SPRING, GOVERNOR | MODEL K4

12677-36F30

Unavailable

27

SPRING, GOVERNOR | MODEL K5/K6

12677-36F40

Unavailable

28

GOVERNOR SET, EXHAUST | MODEL K4

12670-36820

Unavailable

28

GOVERNOR SET, EXHAUST | MODEL K5/K6

12670-36830

$115.72
