Suzuki RM125 (2006) ELECTRICAL (MODEL K4) Diagram

#

Description
Price

1

CDI UNIT

32900-36F20

Unavailable

2

BAND, CDI UNIT

32942-14301

$11.89

3

PROTECTOR (170X95X3) | CUT AS REQUIRED PROFILE (40X85)

33651-37000

$4.48

4

COIL ASSY, IGNITION

33410-37F00

$127.20

5

BOLT (6X16)

09103-06234

$2.35

6

CAP, SPARK PLUG

33510-20A02

$24.39

7

SWITCH ASSY,ENGINE STOP | Includes Item(s) 8

37820-36E00

$25.46

8

SCREW

02112-33165

$1.49

9

CLAMP (L:120)

09407-12402

$3.04

10

HARNESS, WIRING

36610-36F20

Unavailable

11

CLAMP (L:90)

09407-11402

$1.80

12

CLAMP (L:45)

09404-06429

$1.83
