Suzuki RM125 (2006) AIR CLEANER (MODEL K4/K5/K6) Diagram

#

Description
Price

1

CLEANER ASSY, AIR | MODEL K4 This part replaces 13700-36F30.

13700-36F31

Unavailable

1

CLEANER ASSY, AIR | MODEL K5

13700-36F31

Unavailable

1

CLEANER ASSY, AIR | MODEL K6; Includes Item(s) 2 - 16

13700-36F50

$452.83

2

FILTER ASSY

13780-37F20

$86.78

3

BASE, FILTER

13790-37F20

$25.08

4

HOLDER, FILTER

13791-37F20

$19.57

5

.BOLT,WING

13831-37F20

$7.38

6

WASHER

13792-13A01

$3.97

7

TUBE, OUTLET

13881-36F30

$113.83

8

CLAMP

09402-70902

$5.09

9

NUT | MODEL K4/K5

08310-00057

$1.83

9

.NUT | MODEL K6 This part replaces 08319-21053.

08319-2105A

$2.21

10

MUD GUARD

13738-36E01

$20.05

11

COLLAR, MUD GUARD

13838-02B00

$3.26

12

.SCREW

13831-35F00

$2.51

13

COVER, AIR CLEANER | MODEL K4/K5

13749-37F30

Unavailable

14

PLATE

13795-37F20

$19.97

15

GASKET

13796-37F20

$15.50

16

CUSHION, AIR CLEANER | MODEL K4/K5

13736-37F30

Unavailable

16

CUSHION, AIR CLEANER | MODEL K6

13736-37F50

$21.45

17

CAP, AIR CLEANER

13741-36F30

$23.38

18

NUT This part replaces 71812-82010.

09148-06021

$3.35

19

BOLT, AIR CLEANER

09103-06256

$2.27

20

WASHER (6.3X16X1) This part replaces 09169-06054.

09169-06053

$1.10
