Description

Price

1

GEAR ASSY, PRIMARY DRIVEN | NT:64/18 This part replaces 21200-43D02.

21200-43D04

Unavailable

2

SPACER

21251-43D00

$35.74

3

WASHER

08211-20363

$3.18

4

BEARING (25X30X21.8)

09263-25046

$25.92

5

HUB, CLUTCH SLEEVE This part replaces 21411-43D02.

21411-43D04

$104.18

6

PLATE, DRIVE (T:2.8)

21441-43D00

$22.37

7

PLATE, DRIVEN (T:1.4)

21451-43D00

$10.00

8

DISC, CLUTCH PRESSURE This part replaces 21462-43D00.

21462-43D01

$40.76

9

SPRING, CLUTCH This part replaces 09440-18026.

09440-18030

$6.51

10

BOLT (5X18)

09116-05019

$2.32

11

NUT

09140-20001

$3.37

12

LOCK WASHER

09167-20009

$2.03

13

RACK

23165-46000

$22.21

14

CIRCLIP | FOR 23165-46000 This part replaces 08331-31106.

08331-31109

$1.78

15

THRUST BEARING (10.1X22X2.8)

09263-10002

$10.19

16

PINION

23261-00B20

Unavailable

17

BEARING (9X13X10)

09263-09001

$14.53

18

BEARING (12X16X10)

09263-12024

$12.67

19

OIL SEAL (10X17X5)

09285-10004
