Suzuki RM100 (1981) REAR SWINGING ARM (RM100N) Diagram

#

Description
Price

1

REAR SWINGING ARM SET | GOLD; Includes Item(s) 2 - 4

61100-40832-08C

Unavailable

2

BUSHING

61261-40201

Unavailable

3

SPACER, CENTER This part replaces 61280-40200.

61280-40201

Unavailable

4

BEARING, CENTER (17X24X20) This part replaces 09263-17011.

09263-17027

$19.48

5

SHAFT, PIVOT

61211-40201

Unavailable

6

COVER SWGARM PIVOT This part replaces 61262-40200.

61262-03B01

$11.18

7

SPACER

61251-40200

Unavailable

8

THRUST WASHER

08211-12282

$2.65

9

WASHER This part replaces 08322-11128.

08322-01127

$1.84

10

NUT This part replaces 08314-41128.

08314-4012A

$2.50

11

PIN This part replaces 04111-20308.

04111-2030A

$1.50

12

BUFFER, CHAIR, DEFENSE NO.1

61273-40210

Unavailable

13

BUFFER, CHAIN DEFENSE NO.2

61274-40210

Unavailable

14

SCREW

03221-04168

Unavailable

15

SCREW

02142-05107

$1.49

16

SHOCK ABSORBER, REAR

62100-40210

Unavailable

16

SHOCK ABSORBER, REAR | F.NO.29518~

62100-40211

Unavailable

17

BOLT

09100-08150

Unavailable

18

WASHER This part replaces 08322-11088.

08322-01087

$2.13

19

BOLT 10X 40 This part replaces 09100-10096.

09100-10184

$3.16

20

LOCK WASHER This part replaces 08321-21108.

08321-01107

$1.84

21

SPACER

62316-40200

Unavailable

22

TORQUE LINK, REAR

64310-40200

Unavailable

23

BEARING This part replaces 64337-40400.

64337-40401

Unavailable

24

WASHER

09164-08011

$2.71

25

NUT This part replaces 08310-12088.

08310-00087

$2.13

26

DUST SEAL

64338-40400

Unavailable

27

.COTTER PIN This part replaces 04111-20158.

04111-2015A

$1.49

28

BOLT

09101-08003

Unavailable

29

WASHER This part replaces 08322-11088.

08322-01087

$2.13

30

NUT This part replaces 08314-41088.

08314-4008B

$3.03

31

COTTER PIN This part replaces 04111-20208.

04111-2020A

$1.49

32

BOLT This part replaces 01107-10408.

01500-10407

$3.55

33

WASHER This part replaces 08322-11108.

08322-01107

$2.15

34

NUT This part replaces 08319-21108.

09159-10027

$3.10
