- RM-Z250 (2005)
WHEEL/TIRE
Suzuki RM-Z250 (2005) WHEEL/TIRE Diagram
#
Description
Price
41009
TIRE,FR,80/100-21 51M,M401(BS)
K4100-90064
Unavailable
41009A
TIRE,RR,100/90-19 57M,M402(BS)
K4100-90076
Unavailable
41022
TUBE-TIRE,MC90/90-21(BS)
K4102-21107
Unavailable
41022A
TUBE-TIRE,100/90-19(BS)
K4102-21142
Unavailable
41023
BAND-RIM,X-21(BS)
K4102-31009
Unavailable
41023A
BAND-RIM,110/90-19(BS)
K4102-31081
Unavailable
41024
STOPPER-RIM,1.60-M(DUNLOP)
KK410-24010
Unavailable
41024A
STOPPER-RIM,1.85-M(DUNLOP)
KK410-24011
Unavailable
41024B
STOPPER-RIM,1.85-M(DUNLOP) | OPTION
KK410-24011
Unavailable
41025
RIM,FR,1.60X21
K4102-50004
Unavailable
41025A
RIM,RR,1.85X19
K4102-50005
Unavailable
41025B
RIM,FR,1.85X20
K4102-51411
Unavailable
41029
SPOKE-INNER,FR,230MMX165D
K4102-90007
Unavailable
41029B
SPOKE-INNER,RR,204MMX159D
K4102-91330
Unavailable
41030
SPOKE-OUTER,FR,231.5MMX170D
K4103-00003
Unavailable
41030A
SPOKE-OUTER,FR,217.5MMX170D
K4103-01172
Unavailable
41032
NIPPLE-SPOKE,ALUMINUM
K4103-20002
Unavailable
41032A
NIPPLE SPOKE,8X | OPTION This part replaces K4103-21077.
K4103-20003
Unavailable
41032B
NIPPLE-SPOKE,STEEL | OPTION
K4103-21085
Unavailable
41090
WHEEL,FR,1.60X21,ALUM NIPPLE | OPTION
K4109-00002
Unavailable
41090A
WHEEL,RR,1.85X19,ALUM NIPPLE | OPTION
K4109-00003
Unavailable
41090B
WHEEL,FR,1.85X20,ALUM NIPPLE | OPTION
K4109-01154
Unavailable
92045
BEARING-BALL,69042RS
K9204-51284
Unavailable
92049
SEAL-OIL,BJNC-2 25X37X5
K9204-91403
Unavailable
92152
COLLAR,FRONT BRAKE DRUM,L=72
K9215-21472
Unavailable
92161
DAMPER,RIM STOPPER
K9216-11184
Unavailable
