Suzuki RM-Z250 (2005) CRANKSHAFT Diagram

#

Description

Price

13031

CRANKSHAFT COMP This part replaces K1303-10016.

K1303-10074

Unavailable

13032

ROD,CONNECTING This part replaces K1303-20003.

K1303-20047

Unavailable

13034

BEARING,BIG END This part replaces K1303-40007.

K1303-40014

Unavailable

13035

PIN,CRANK This part replaces K1303-50001.

K1303-50015

Unavailable

13037

NO DESCRIPTION AVAILABLE This part replaces K1303-70015.

K1303-75095

Unavailable

13037A

CRANKSHAFT,RH

K1303-70016

Unavailable

13097

GEAR,PRIMARY SP This part replaces K1309-70008.

K1309-70117

$70.38

92022

WASHER,16.5X27X1.4

KK920-22054

$5.73

92210

NUT,16MM

K9221-00069

$4.28
