Kawasaki RIDGE® XR DELUXE HVAC Carrier(s) Diagram

#

Description
Price

11058

BRACKET,CARRIER LATCH

11058-0092

$10.90

11058A

BRACKET

11058-0675

$2.00

13236

LEVER-COMP,CARRIER LATCH

13236-0874

$99.00

13236A

LEVER-COMP

13236-0891

$53.26

13272

PLATE

13272-4064

$12.41

13272A

PLATE,HEAT INSULATOR

13272-4065

$112.62

13272B

PLATE

13272-4178

$1.08

13272C

PLATE,CARRIER LATCH,LH

13272-4185

$7.90

13272D

PLATE,CARRIER LATCH,RH

13272-7017

$24.58

13272E

PLATE,TAIL GATE LATCH

13272-7074

$2.54

14093

COVER,FRONT CARRIER

14093-1311

$43.45

14093A

COVER,SIDE CARRIER,INNER,LH

14093-1314

$40.42

14093B

COVER,SIDE CARRIER,INNER,RH

14093-1315

$40.42

16073

INSULATOR,HEAT,FR

16073-0948

$126.69

16073A

INSULATOR,HEAT,RR

16073-0962

$1.78

16146

COVER-ASSY,SIDE CARRIER,OUT,LH

16146-0922

$56.99

16146A

COVER-ASSY,SIDE CARRIER,OUT,RH

16146-0923

$56.99

16146B

COVER-ASSY,TAIL GATE

16146-0940

$65.32

27012

HOOK,CARRIER BOTTOM

27012-0900

$3.75

31064

PIPE-COMP,TAIL GATE,LWR

31064-0745

$40.79

31064A

PIPE-COMP,TAIL GATE,UPP

31064-0798

$61.63

39188

TAPE,25X47X0.18

39188-0612

$3.66

44095

DAMPER-GAS FILLED

44095-0002

$39.13

46075

GRIP,CARRIER LATCH

46075-0672

$6.58

53029

CARRIER,BASE

53029-0373

$530.21

53029A

CARRIER,BOTTOM

53029-0374

$200.15

53045

HOOK-ASSY,TAIL GATE

53045-0040

$8.22

53062

GATE-TAIL,INNER

53062-0031

$72.59

92004

STUD

92004-0733

$2.44

92009

SCREW,TAPPING,5X14

92009-1197

$2.99

92022

WASHER,8.2X19X2

92022-1533

$4.85

92022A

WASHER,PLAIN,6.5X20X1

92022-165

$3.29

92027

COLLAR,L=4.6

92027-1168

$3.81

92027A

COLLAR

92027-1767

$4.18

92039

RIVET

92039-0776

$0.80

92039A

RIVET,6.35X17.9

92039-0856

$0.93

92043

PIN,12.4X72.4

92043-0716

$7.15

92077

KNOB,TAIL GATE

92077-0041

$9.25

92145

SPRING

92145-2268

$11.64

92145A

SPRING

92145-2443

$4.29

92145B

SPRING

92145-2444

$4.29

92152

COLLAR,6.8X20X4.6

92152-2432

$4.17

92152A

COLLAR,6.2X9.5X9.8

92152-2917

$2.00

92152B

COLLAR,6.2X9.5X6

92152-2918

$1.93

92152C

COLLAR,6.2X9.5X3.5

92152-3860

$7.90

92154

BOLT,SOCKET,6X18

92154-1026

$1.44

92161

DAMPER,10X20X8

92161-0855

$3.25

92161A

DAMPER,10X34X10

92161-1920

$1.20

92161B

DAMPER

92161-2505

$1.66

92161C

DAMPER

92161-2524

$1.02

92172

SCREW,6X16

92172-0284

$0.90

92172A

SCREW,TAPPING,6X16

92172-0739

$0.73

92172B

SCREW,TAPPING,6X16

92172-1470

$0.74

92172C

SCREW,TAPPING,6X16

92172-1471

$4.18

130

BOLT-FLANGED,5X10

130BA0510

$1.27

130A

BOLT-FLANGED,6X14

130BA0614

$0.97

130B

BOLT-FLANGED,6X18

130BB0618

$1.33

130C

BOLT-FLANGED,6X22

130BB0622

$2.79

130D

BOLT-FLANGED,6X18

130CB0618

Unavailable

554

PIN-SNAP,12MM

554DA1200

$2.63
