Description

Price

11013

ELEMENT-AIR FILTER,HVAC,OUT

11013-0839

$6.89

11058

BRACKET,HVAC

11058-0261

$11.81

13272

PLATE,HVAC FILTER,OUT

13272-7051

$9.87

13272A

PLATE,HVAC FILTER,IN

13272-7080

$8.16

14073

DUCT,HVAC,SIDE

14073-1883

$49.22

14073A

DUCT,HVAC,CENTER

14073-1884

$37.56

14073B

DUCT,HVAC,DEFROSTER

14073-1885

$48.48

14093

COVER,CUP HOLDER

14093-1329

$3.94

14093A

COVER,GLOVE BOX

14093-1337

$18.23

14093B

COVER,STORAGE BOX,SIDE,LWR

14093-1338

$6.96

14093C

COVER,STORAGE BOX,SIDE,UPP,GRY

14093-1339-72J

$17.43

14093D

COVER,LOUVER,SIDE,S.BLACK

14093-1373-839

$6.63

14093E

COVER,LOUVER,CNT,S.BLACK

14093-1374-839

$10.53

14093F

COVER,HVAC CONTROLLER

14093-1377

$12.04

14093G

COVER,NAVIGATION

14093-1438

$6.82

14093H

COVER,NAVIGATION BEZEL,S.BLACK

14093-1439-839

$12.29

21177

CONTROLLER,HVAC

21177-0009

$549.41

27017

LOCK,PUSH

27017-0572

$22.48

39350

PANEL,DASHBOARD

39350-0005

$107.99

54010

CABLE,HVAC MODE

54010-0654

$96.27

54010A

CABLE,HVAC TEMP

54010-0655

$103.84

54010B

CABLE,HVAC R/F

54010-0656

$59.44

59226

PANEL-CONTROL,LH,D.GRAY

59226-0763-72J

$41.69

59226A

PANEL-CONTROL,RH,D.GRAY

59226-0764-72J

$41.69

59226B

PANEL-CONTROL,CNT

59226-0768

$37.42

59228

LOUVER,CENTER

59228-0001

$6.90

59228A

LOUVER,SIDE

59228-0002

$10.69

92009

SCREW,TAPPING,6X16

92009-1166

$5.52

92039

RIVET

92039-0776

$1.19

92093

SEAL

92093-0776

$2.59

92093A

SEAL,15X15X235

92093-0782

$7.33

92093B

SEAL,10X10X110

92093-0785

$2.80

92093C

SEAL,10X10X60

92093-0786

$1.86

92093D

SEAL,10X6X705

92093-0795

$14.75

92093E

SEAL

92093-0816

$5.35

92093F

SEAL,HVAC FILTER,OUT

92093-0824

$24.05

92093G

SEAL,HVAC FILTER,IN

92093-0825

$8.85

92145

SPRING,REAR BRAKE

92145-2219

$2.18

92152

COLLAR,6.3X9.5X4.1

92152-1571

$6.00

92172

SCREW,TAPPING,5X10

92172-0262

$1.34

92173

CLAMP

92173-1423

$1.48

92210

NUT

92210-1796

$0.39

Kawasaki Ridge Limited Front Box Diagram

ELEMENT-AIR FILTER,HVAC,OUT

BRACKET,HVAC

PLATE,HVAC FILTER,OUT

PLATE,HVAC FILTER,IN

DUCT,HVAC,SIDE

DUCT,HVAC,CENTER

DUCT,HVAC,DEFROSTER

COVER,CUP HOLDER

COVER,GLOVE BOX

COVER,STORAGE BOX,SIDE,LWR

COVER,STORAGE BOX,SIDE,UPP,GRY

COVER,LOUVER,SIDE,S.BLACK

COVER,LOUVER,CNT,S.BLACK

COVER,HVAC CONTROLLER

COVER,NAVIGATION

COVER,NAVIGATION BEZEL,S.BLACK

CONTROLLER,HVAC

LOCK,PUSH

PANEL,DASHBOARD

CABLE,HVAC MODE

CABLE,HVAC TEMP

CABLE,HVAC R/F

PANEL-CONTROL,LH,D.GRAY

PANEL-CONTROL,RH,D.GRAY

PANEL-CONTROL,CNT

LOUVER,CENTER

LOUVER,SIDE

SCREW,TAPPING,6X16

RIVET

SEAL

SEAL,15X15X235

SEAL,10X10X110

SEAL,10X10X60

SEAL,10X6X705

SEAL

SEAL,HVAC FILTER,OUT

SEAL,HVAC FILTER,IN

SPRING,REAR BRAKE

COLLAR,6.3X9.5X4.1

SCREW,TAPPING,5X10

CLAMP

NUT
