- RIDGE® HVAC
Door(LH)
Kawasaki RIDGE® HVAC Door(LH) Diagram
#
11065
CAP,WINDOW ACTUATOR
11065-1432
$1.58
13272
PLATE,FULL DOOR,LH
13272-4426
$18.52
13280
HOLDER,WINDOW,INNER
13280-1342
$8.95
13280A
HOLDER,WINDOW,OUTER
13280-1343
$10.13
14093
COVER,FULL DOOR,LH,INNER
14093-1321
$94.25
14093A
COVER,FULL DOOR,LH,OUTER,S.BLK
14093-1322-839
$113.08
14093B
COVER,FULL DOOR,LH,INNER,UPP
14093-1365
$72.57
14093C
COVER,FULL DOOR,LH,OUTER,UPP
14093-1366
$61.08
14094
COVER,DOOR,CORNER
14094-0146
$9.46
16172
ACTUATOR,WINDOW,LH
16172-0563
$416.52
27012
HOOK,DOOR
27012-0860
$8.54
27016
LOCK-ASSY,FR DOOR,LH
27016-0114
$206.20
27016A
LOCK-ASSY,DOOR,LH
27016-0121
$179.82
39145
TRIM-SEAL,WINDOW,LWR
39145-0745
$18.95
39145A
TRIM-SEAL,WINDOW,LWR
39145-0763
$18.95
39145B
TRIM-SEAL,WINDOW,UPP
39145-0796
$6.95
39145C
TRIM-SEAL,FULL DOOR,RAIL,FR
39145-0799
$20.24
39145D
TRIM-SEAL,FULL DOOR,RAIL,RR
39145-0800
$17.16
39145E
TRIM-SEAL,FULL DOOR
39145-0801
$45.24
39201
FRAME-COMP-DOOR,FULL,LH
39201-0009
$408.74
46001
HANDLE-ASSY,DOOR,OUTER
46001-0017
$28.37
46001A
HANDLE-ASSY,DOOR,INNER
46001-0026
$25.68
46075
GRIP,DOOR,INNNER,LH
46075-0665
$4.90
46102
ROD,DOOR,LH
46102-0674
$40.29
53200
WINDOW,GLASS
53200-0001
$78.76
54010
CABLE,DOOR HANDLE
54010-0653
$17.72
54010A
CABLE,FR DOOR HANDLE
54010-0671
$17.67
92009
SCREW,TAPPING,6X16
92009-1166
$5.52
92039
RIVET,4.0X17.5
92039-0703
$0.99
92039A
RIVET
92039-0776
$1.19
92072
BAND,OS170-FT7(BLACK)
92072-1414
$3.74
92075
DAMPER,HANDLE HOLDER
92075-039
$4.69
92093
SEAL,10X10X110
92093-0785
$2.80
92093A
SEAL
92093-0792
$18.21
92139
BUSHING
92139-0230
$4.61
92139A
BUSHING
92139-1241
$2.25
92152
COLLAR,6.5X8.5X5.5
92152-0612
$3.90
92152A
COLLAR,6.3X9.5X4.1
92152-1571
$6.00
92161
DAMPER
92161-1084
$2.67
92161A
DAMPER
92161-1531
$3.02
92161B
DAMPER,6X19X5.6
92161-1911
$0.90
92161C
DAMPER
92161-2612
$0.98
92161D
DAMPER
92161-2613
$2.91
92161E
DAMPER,18X345X3
92161-2637
$3.42
92161F
DAMPER,15X45X13
92161-2638
$4.33
92161G
DAMPER,20X250X10
92161-2648
$8.55
92161H
DAMPER,20X550X10
92161-2649
$21.87
92161I
DAMPER,25X130X10
92161-2714
$16.55
92161J
DAMPER,10X20X6
92161-2745
$3.08
92172
SCREW,6X16
92172-0236
$0.85
92172A
SCREW,6X16
92172-0284
$1.34
92172B
SCREW,TAPPING,6X16
92172-1470
$0.86
92173
CLAMP
92173-2863
$2.76
92200
WASHER
92200-2144
$0.80
92210
NUT,LOCK,FLANGED,6MM
92210-0303
$1.34
130
BOLT-FLANGED,6X10
130BA0610
$1.20
130A
BOLT-FLANGED,6X12
130BA0612
$1.72
130B
BOLT-FLANGED,6X18
130BA0618
$1.54
411
WASHER-PLAIN,10MM
411AA1000
$0.96
