Kawasaki RIDGE® CREW HVAC Seat(Rear) Diagram

#

Description
Price

11058

BRACKET,SEAT BACK

11058-0244

$18.23

11058A

BRACKET,SEAT BACK,CNT

11058-0516

$13.05

11065

CAP

11065-0901

$2.94

23062

BRACKET-COMP,SEAT BOTTOM

23062-1389

$54.28

44095

DAMPER-GAS FILLED

44095-0004

$20.20

53007

FRAME-SEAT,BOTTOM,PASSENGER

53007-0460

$281.91

53007A

FRAME-SEAT,BACK,DRIVER

53007-0461

$61.02

53007B

FRAME-SEAT,BOTTOM,RH

53007-0464

$346.61

53007C

FRAME-SEAT,RR BOTTOM

53007-0495

$85.85

53007D

FRAME-SEAT,RR BOTTOM,CNT

53007-0515

$147.51

53007E

FRAME-SEAT,RR,BACK,PASSENGER

53007-0536

$116.70

53045

HOOK-ASSY

53045-0019

$7.79

53061

BELT-SEAT,BUCKLE

53061-0039

$31.80

53061A

BELT-SEAT,CNT

53061-0377

$92.72

53061B

BELT-SEAT,LH/RH

53061-0378

$106.86

53066

SEAT,BOTTOM,PASSENGER,BLK+SIL

53066-0867-55P

$309.12

53066A

SEAT-ASSY,BACK,BLACK+SIL+SIL

53066-0868-41H

$293.76

53066B

SEAT-ASSY,BACK,CNT,BLACK

53066-0869-MA

$160.35

53066C

SEAT,BOTTOM,DRIVER,BLK+SIL

53066-0870-55P

$212.29

92004

STUD

92004-0733

$3.04

92022

WASHER,8.2X19X2

92022-1533

$5.52

92043

PIN

92043-1773

$13.59

92145

SPRING,SEAT LATCH

92145-0022

$7.15

92154

BOLT,FLANGED,10X16

92154-7395

$9.46

92154A

BOLT,FLANGED,10X19.5

92154-7396

$9.09

92161

DAMPER

92161-1065

$3.73

92161A

DAMPER

92161-1084

$2.67

92161B

DAMPER,SEAT

92161-1489

$3.35

92172

SCREW,TAPPING,5X16

92172-0427

$2.55

92172A

SCREW,TAPPING,6X20

92172-0488

$3.02

92173

CLAMP

92173-1423

$1.48

92200

WASHER,16X22X2

92200-1798

$1.34

120

BOLT-SOCKET,8X14

120CA0814

$4.67

130

BOLT-FLANGED,12X20

130BA1220

$3.74

130A

BOLT-FLANGED,8X16

130CA0816

$2.49

130B

BOLT-FLANGED,10X50

130CA1050

$3.71

132

BOLT-FLANGED-SMALL,6X14

132BB0614

$2.49

482

CIRCLIP-TYPE-E,12MM

482EA0200

$2.30
