Kawasaki RIDGE® CREW HVAC Frame Fittings(Rear) Diagram

#

Description
Price

13272

PLATE,VENT FLAP

13272-4095

$13.88

14073

DUCT,VENT

14073-1921

$15.71

14093

COVER,TUNNEL,CNT

14093-1330

$38.73

14093A

COVER,TRAY

14093-1333

$8.19

14093B

COVER,HOLE

14093-1334

$4.41

14093C

COVER,RR

14093-1353

$54.16

16073

INSULATOR,FR TUNNEL&BACK PANEL

16073-0947

$21.59

16073A

INSULATOR,SEAT PANEL,LH

16073-0967

$52.68

16073B

INSULATOR,SEAT PANEL,CNT

16073-0968

$45.75

16073C

INSULATOR,SEAT PANEL,RH

16073-0969

$53.13

16073D

INSULATOR

16073-0984

$47.08

39320

FLOOR,PANEL,LH

39320-0001

$44.68

39320A

FLOOR,PANEL,RH

39320-0002

$42.88

39350

PANEL,UNDER SEAT

39350-0010

$125.01

39350A

PANEL,BACK

39350-0012

$108.11

92009

SCREW,TAPPING,6X16

92009-1166

$5.52

92039

RIVET

92039-0776

$1.19

92093

SEAL,10X10X395

92093-0780

$9.93

92093A

SEAL,10X10X60

92093-0786

$1.86

92093B

SEAL,3X5X310

92093-0818

$4.52

92093C

SEAL,3X5X500

92093-0819

$11.62

92152

COLLAR,6.3X9.5X4.1

92152-1571

$6.00

92161

DAMPER

92161-2613

$2.91

92161A

DAMPER

92161-2626

$1.22

92161B

DAMPER,12X36X1.5

92161-2627

$1.39

92161C

DAMPER,10X370X1.5

92161-2628

$2.20

92161D

DAMPER

92161-2629

$3.11

92161E

DAMPER

92161-2630

$3.11

92161F

DAMPER,38X220X1.5

92161-2631

$2.91

92161G

DAMPER

92161-2632

$3.19

92161H

DAMPER,20X200X20

92161-2633

$17.39

92172

SCREW,6X16

92172-0284

$1.34

92172A

SCREW,TAPPING,6X16

92172-1470

$0.86

92173

CLAMP

92173-1423

$1.48

92210

NUT

92210-1796

$0.39
