Suzuki RE5 (1976) GENERATOR Diagram

#

Description
Price

1

GENERATOR ASSY | M,A; Includes Item(s) 2 - 4

31400-37010

Unavailable

2

STATOR ASSY | M,A

31401-37010

Unavailable

3

COIL ASSY, FIELD | M,A

31421-37010

Unavailable

4

ROTOR | M,A

31402-37010

Unavailable

5

SCREW | M,A This part replaces 02112-06258.

02112-06257

$1.78

6

SCREW | M,A This part replaces 02112-06358.

02112-06357

$1.78

7

NO DESCRIPTION AVAILABLE | M,A This part replaces 01122-12508.

01550-12503

Unavailable

8

GROMMET | M,A

09309-08007

Unavailable

9

WASHER | M,A This part replaces 09164-12014.

09164-12016

Unavailable

10

CLAMP | M,A This part replaces 09407-14301.

09407-18302

$2.28

11

CLAMP | M,A This part replaces 09404-06402.

09404-06039

$1.74

12

REGULATOR VOLTAGE | M,A; FROM 32500-37010

32500-31010

Unavailable

13

BOLT, CANISTER | M,A This part replaces 01112-06168.

01500-06167

$1.97

14

LOCK WASHER | M,A This part replaces 08321-21068.

08321-01067

$2.13

15

RECTIFIER ASSY | M,A; TO 32800-31010 This part replaces 32800-37010.

32800-31021

Unavailable

16

.NUT | M,A This part replaces 08311-11068.

08310-00067

$2.13

17

LOCK WASHER | M,A This part replaces 08321-21068.

08321-01067

$2.13
