Can-Am Rally 175, 2004 01- Crankshaft, Piston And Cylinder Diagram

#

Description
Price

1

GASKET - Call your local BRP dealership

420650165

Unavailable

2

Cylinder Ass’y | Includes 2 To 3

420613346

Unavailable

3

Drive Pin 5 X 10

420929650

Unavailable

4

GASKET - Call your local BRP dealership

420650172

Unavailable

5

CYLINDER HEAD ASS?Y - Call your local BRP dealership | Includes 5 - 7.

420613110

Unavailable

6

VALVE GUIDE - Call your local BRP dealership

420253811

Unavailable

7

PROTECTION PLUG - Call your local BRP dealership

420960775

Unavailable

8

STUD - Call your local BRP dealership

420240366

Unavailable

9

Hex. Nut M8

420842616

Unavailable

10

Socket Head Screw M6 X 90

420241481

Unavailable

11

Socket Head Screw M6 X 30

205063044

Unavailable

12

Thermostat 65° With Gasket Ass'y | Includes 42 to 43

420222494

Unavailable

13

Thermostat Gasket

420650300

Unavailable

14

Thermostat Cover

420222470

Unavailable

15

Screw M5 X 16

420441621

Unavailable

16

Gasket Ring

420650255

Unavailable

17

Socket Screw M5 x 12

420241841

Unavailable

18

Washer 5.3

420927574

Unavailable

19

HOSE CLAMP - Call your local BRP dealership

420251052

Unavailable

20

Chain Tension Piston

420236490

Unavailable

21

Compression Spring

420238100

Unavailable

22

HEX. SCREW M18 X 10 - Call your local BRP dealership

420552276

Unavailable

23

Crush Washer

420552280

Unavailable

24

Valve Cover

420610440

Unavailable

25

Valve Cover Gasket

420650230

Unavailable

26

Socket Head Screw M6 X 20

205062044

Unavailable

27

Thermostatic Switch

420265392

Unavailable

28

GASKET SET - Call your local BRP dealership

420296407

Unavailable

29

Loctite 243, 10 ml

293800060

Unavailable

30

LUBRICANT LOCTITE LB 8150 236ML - Call your local BRP dealership

219704461

Unavailable
