Yamaha RA760U (WAVE RAIDER 760) 1996 HULL - DECK Diagram

#

Description

Price

1

STRAINER, BILGE

GD0-6761D-00-00

Unavailable

2

BASE, STRAINER BLIGE

EW2-67618-00-00

Unavailable

3

SCREW, TAPPING(61A)

97780-50612-00

Unavailable

4

BAND

90601-200U1-00

Unavailable

5

HOSE

90445-19M04-00

Unavailable

6

JOINT, HOSE

61X-51162-00-00

Unavailable

7

CLAMP (6E5)

90465-13M11-00

$8.49

8

HOSE

90445-19M01-00

Unavailable

9

PACKING, HOSE 2

GJ1-67578-10-00

Unavailable

10

CONNECTION, THRU-HULL 1/4

90604-80759-00

Unavailable

11

CONNECTION, THROUGH HALL (GD0)

90604-80775-00

Unavailable

12

GASKET

90430-13909-00

Unavailable

13

BAND

90601-200U1-00

Unavailable

14

DRAIN PLUG ASSY

EU0-62280-00-00

Unavailable

15

. PLUG, DRAIN

EU0-62282-00-00

Unavailable

16

. O-RING

EU0-62283-00-00

Unavailable

17

. PACKING DRAIN (EU0)

EU0-62285-01-00

Unavailable

18

SCREW, PAN HEAD(6A1)

97885-05020-00

Unavailable

19

. WASHER, PLAIN

92990-05200-00

Unavailable

20

NUT, FLANGE

95720-05300-00

Unavailable

21

CLAMP COMP (EU0)

90600-91736-00

Unavailable

22

. WASHER, PLAIN

90201-05925-00

Unavailable

23

RIVET, BLIND

90267-48802-00

Unavailable

24

BAND (EU0)

90601-20009-00

Unavailable

25

BOWEYE 1

FN8-U1624-00-00

Unavailable

26

. NUT, SELF-LOCKING

95720-08300-00

Unavailable

27

WASHER, PLAIN

92990-08200-00

Unavailable

28

STABILIZER LH

GH1-6883N-50-00

Unavailable

29

STABILIZER RH

GH1-6883P-50-00

Unavailable

30

COLLAR(GH1)

90387-06916-00

Unavailable

31

BRACKET, STABILIZER

GH1-6883T-00-00

Unavailable

32

YBS66-6 WASHER, PLAIN

92990-06200-00

Unavailable

33

WASHER, PLATE

90201-06020-00

Unavailable

34

NUT

90179-06959-00

Unavailable

35

NUT(650)

95380-06700-00

Unavailable

36

SPOUT

FN8-6269B-00-00

Unavailable

37

NUT

EU0-61652-00-00

Unavailable

38

CLAMP

90465-10098-00

Unavailable
