Honda QA50K1A MOTORCYCLE, JPN, VIN# QA50-2000001 FRONT WHEEL Diagram

#

Description
Price

1

RIM, RR. WHEEL *NH0* (CHAMPIONSHIP WHITE) (NOT AVAILABLE)

42701-114-000A

Unavailable

2

AXLE, FR. WHEEL

44301-045-010

Unavailable

3

COLLAR, FR. WHEEL SIDE

44311-045-670

$5.08

4

HUB, FR. WHEEL *NH0* (CHAMPIONSHIP WHITE) (NOT AVAILABLE)

44601-114-010A

Unavailable

5

COLLAR, FR. AXLE DISTANCE

44620-045-020

Unavailable

6

TIRE, FR. (4.00-5) (NITTO) (NOT AVAILABLE) This part replaces 44711-114-003.

44711-114-006

Unavailable

6

TIRE, FR. (4.00-5) (NITTO) (NOT AVAILABLE)

44711-114-006

Unavailable

7

TUBE (400X5) (TR-244) (NOT AVAILABLE) This part replaces 08400-04500.

44712-114-003

Unavailable

7

TUBE (400X5) (TR-244) (NOT AVAILABLE)

44712-114-003

Unavailable

8

PANEL, RR. BRAKE *CLEAR* (CLEAR) (NOT AVAILABLE) This part replaces 45100-045-020.

45100-045-020ZA

Unavailable

8

PANEL, RR. BRAKE *NO_CODE* (NO COLOR NAME ASSIGNED) (NOT AVAILABLE)

45100-045-020ZA

Unavailable

9

SHOE, BRAKE (N/A: USE P/N 451A0-001-670)

45120-001-010

Unavailable

10

CAM, RR. BRAKE (NOT AVAILABLE)

45131-045-000

Unavailable

11

SPRING, BRAKE SHOE

45133-028-000

$2.03

12

ARM, FR. BRAKE

45410-045-405

Unavailable

12

ARM, FR. BRAKE This part replaces 45410-045-670.

45410-045-405

Unavailable

13

NUT, FR. BRAKE ARM SETTING

45436-001-000

$1.80

14

NUT, SELF-LOCK (12MM)

90353-045-000

$5.99

15

WASHER, RR. BRAKE ARM

90525-001-000

$1.95

16

OIL SEAL (21X35X5.5) This part replaces 91252-001-020.

91252-001-023

$6.14

16

OIL SEAL (21X35X5.5)

91252-001-023

$6.14

17

BOLT, HEX. (6X16) This part replaces 92000-06016.

92101-06016-0A

$1.49

17

BOLT, HEX. (6X16) This part replaces 92000-06016-0A.

92101-06016-0A

$1.49

17

BOLT, HEX. (6X16) This part replaces 92000-06016-1A.

92101-06016-0A

$1.49

17

BOLT, HEX. (6X16) This part replaces 92100-06016-0A.

92101-06016-0A

$1.49

17

BOLT, HEX. (6X16)

92101-06016-0A

$1.49

17

BOLT, HEX. (6X16) This part replaces 92200-06016-0A.

92101-06016-0A

$1.49

18

BOLT, HEX. (6X25) This part replaces 92000-06025.

92101-06025-0A

$1.62

18

BOLT, HEX. (6X25)

92101-06025-0A

$1.62

19

WASHER, PLAIN (12MM)

94101-12000

$1.49

20

WASHER, SPRING (6MM)

94111-06000

$1.49

21

CIRCLIP (INNER) (32MM)

94520-32000

$1.69

22

BEARING, RADIAL BALL (6201) This part replaces 96100-62010.

96100-62010-00

$8.08

22

BEARING, RADIAL BALL (6201)

96100-62010-00

$8.08

23

BEARING, RADIAL BALL (6201U) This part replaces 96140-62010.

96140-62010-00

$9.63

23

BEARING, RADIAL BALL (6201U)

96140-62010-00

$9.63
