Yamaha PZ50XTGB (PHAZER XTX) 8JT5 2016 CYLINDER HEAD Diagram

#

Description
Price

1

CYLINDER HEAD ASSY

8GC-11101-03-00

Unavailable

2

GUIDE, INTAKE VALVE

5NL-11133-10-00

$44.99

3

PLUG, STRAIGHT SCREW (26H)

90340-20090-00

Unavailable

4

PIN, DOWEL(3XW)

91808-16023-00

$8.49

5

PIN, DOWEL(3XW)

91808-16023-00

$8.49

6

BOLT, WASHER BASED

90105-06027-00

$7.49

7

BOLT, FLANGE

95022-06012-00

$3.29

8

GASKET 256113960000

90430-06014-00

Unavailable

9

BOLT, WITH WASHER

90119-10004-00

$12.49

10

BOLT

91312-06060-00

$10.49

11

CR9EKB NGK SPLUG 10PK

CR9-EKB00-00-00

Unavailable

12

GASKET, CYLINDER HEAD 1

8GC-11181-00-00

$49.99

13

COVER, CYLINDER HEAD 1

8GC-11191-00-00

Unavailable

14

GUIDE, STOPPER 2

5BE-12241-01-00

$29.99

15

GASKET, HEAD COVER 1

8GC-11193-00-00

Unavailable

16

PLUG, OIL

3Y1-15363-10-00

Unavailable

17

O-RING (646)

93210-19123-00

Unavailable

18

PIPE, BREATHER 1

8GC-11166-00-00

Unavailable

19

CLIP

90467-100A1-00

Unavailable

20

BOLT(4BP)

90109-066F0-00

Unavailable

21

RUBBER, MOUNT 1

5VY-1111G-00-00

Unavailable
