Yamaha PZ50MTYW (PHAZER MTX) 8GP50 2009 SHROUD Diagram

#

Description
Price

1

SHROUD

8GC-77111-30-00

$92.43

1

SHROUD

8GC-77111-50-00

$53.11

2

BAND

59V-21646-00-00

$19.49

3

PANEL 1

8GC-2835U-30-00

$58.15

3

PANEL 1

8GC-2835U-40-00

$54.22

4

PANEL 2

8GC-2835V-30-00

$59.45

4

PANEL 2

8GC-2835V-40-00

$55.48

5

BOLT

90109-06220-00

$7.43

6

NUT, SPRING

90183-06100-00

$7.88

7

HOOD 3

8GC-2197H-00-00

$152.05

8

HEAD

3FV-28386-00-00

$22.96

9

WASHER, SPECIAL 1

2TK-21757-00-00

$1.54

10

WASHER, SPECIAL 1

5TJ-21757-00-00

$6.43

11

HOOD 4

8GC-2198H-01-00

$140.37

12

LOUVER 4

8GC-77134-00-00

$25.62

13

CLIP

90468-06001-00

$3.49

14

HEAD

5PW-28386-00-00

$15.04

15

WASHER, SPECIAL 1

2TK-21757-00-00

$1.54

16

FRAME UNDER 1

8GC-2196A-00-00

$68.74

17

PLATE, SPRING

4XV-2177L-01-00

$6.20

18

FRAME, UNDER 2

8GC-2196E-00-00

$71.52

19

PLATE, SPRING

5PW-2177L-01-00

$6.23

20

BOLT

90109-06220-00

$7.43

21

SCREW

90149-06105-00

$4.43

22

NUT, SPRING

90183-06100-00

$7.88

23

PLATE, SPRING

4XV-2177L-01-00

$6.20

24

PLATE, SPRING

5PW-2177L-01-00

$6.23
