Yamaha PZ50FXW (PHAZER FX) 8GN1 2007 STEERING Diagram
#
1
HANDLEBAR
8GN-26111-10-00
$147.99
2
JOINT
8GC-2381B-00-00
Unavailable
3
HOLDER, HANDLE UPPER
1E6-23441-00-00
$27.99
4
BOLT
8GC-23436-00-00
$4.46
5
COLUMN, STEERING 2
8GC-23813-00-00
Unavailable
6
HOLDER, BEARING
8FA-23872-00-00
$14.49
7
PLANE BEARING, STEERING
8FA-23812-00-00
$6.99
8
HOLDER 2
8FA-23867-00-00
Unavailable
9
HOLDER, BEARING
8GC-23872-00-00
Unavailable
10
NUT(6L2)
95333-08600-00
$2.49
11
WASHER, LOCK 1
1UY-23894-01-00
$7.99
12
CAP
8GC-82532-00-00
$5.60
13
COLLAR
90387-09006-00
$7.49
14
PLANE BEARING, STEERING
8GC-23812-00-00
$61.99
15
BEARING
93317-425B7-00
$41.99
16
HOLDER
8GJ-23857-00-00
Unavailable
17
NUT(6L2)
95333-08600-00
$2.49
18
WASHER, LOCK 1
8GJ-23894-00-00
Unavailable
19
ROD, STEERING
8GC-23828-00-00
Unavailable
20
ROD, STEERING RELAY
8GC-23821-00-00
Unavailable
21
JOINT, UNIVERSAL 1
8GC-23841-00-00
Unavailable
22
JOINT, UNIVERSAL 2
8CR-23845-10-00
Unavailable
23
NUT (682)
95380-10700-00
Unavailable
24
NUT, HEXAGON (8A5)
90170-10186-00
Unavailable
25
BOLT, WASHER BASED(47X)
90105-08321-00
Unavailable
26
NUT,FLANGE(J10)
95702-08500-00
Unavailable
27
CLIP
90468-16001-00
Unavailable
28
NUT, FLANGE(3BM)
95704-10500-00
Unavailable
29
CLIP (7U6)
90468-18121-00
Unavailable
30
ARM, CONTROL 1
8GC-2384E-00-00
Unavailable
31
BEARING, CYLINDRICAL(3VR)
93317-41767-00
Unavailable
32
BRACKET 1
8GC-23881-00-00
Unavailable
33
NUT
8GC-23846-00-00
Unavailable
34
WASHER, PLATE
90201-121U3-00
Unavailable
35
NUT, FLANGE(3BM)
95704-10500-00
Unavailable
36
PIN, COTTER
91490-25020-00
Unavailable
37
BOLT, FLANGE
95812-08030-00
Unavailable
38
ARM PIVOT ASSY
8GC-2389K-00-00
Unavailable
39
BUSH
8GC-23526-00-00
Unavailable
40
PIVOT ARM ASSY 2
8GC-2389M-00-00
Unavailable
41
ARM, INSIDE
8GC-2381A-00-00
Unavailable
42
BOLT, SOCKET
91317-08025-00
Unavailable
43
CIRCLIP
8GC-23183-00-00
Unavailable
44
WASHER, PLATE(N04)
90201-124G7-00
Unavailable
45
WASHER PLATE 371115580000
90201-25291-00
Unavailable
46
WASHER, PLATE (5F7)
90201-256E4-00
Unavailable
47
BOLT 1
8GC-23346-00-00
Unavailable
48
95702-12500
95702-12500-00
Unavailable
49
CLIP 136253750000
90468-12006-00
Unavailable
50
WASHER, PLATE
90201-22018-00
Unavailable
51
NUT (26H)
90179-22412-00
Unavailable
52
PIN, COTTER
91402-20035-00
Unavailable
53
BRACKET, PIVOT
8GC-2389H-00-00
Unavailable
54
BEARING
93317-425B7-00
$41.99
55
COLLAR
8GC-23113-00-00
Unavailable
56
BOLT, FLANGE(3GD)
95817-10025-00
Unavailable
57
ARM, IDLER
8GC-23826-00-00
Unavailable
58
BOLT, WASHER BASED(4KD)
90105-10728-00
Unavailable
59
COLLAR
90387-10070-00
Unavailable
60
WASHER, PLATE(JN9)
90201-100S2-00
Unavailable
61
BUSH 1
8GC-23362-00-00
Unavailable
62
NUT, FLANGE(3BM)
95704-10500-00
Unavailable
63
CLIP (7U6)
90468-18121-00
Unavailable
64
ROD, TIE
8GC-23831-00-00
Unavailable
65
JOINT, UNIVERSAL 2
8CR-23845-10-00
Unavailable
66
JOINT, UNIVERSAL 3
8GC-23847-00-00
Unavailable
67
NUT (682)
95380-10700-00
Unavailable
68
NUT, HEXAGON (8A5)
90170-10186-00
Unavailable
69
NUT, FLANGE(3BM)
95704-10500-00
Unavailable
70
CLIP (7U6)
90468-18121-00
Unavailable
71
BOLT
8GC-23493-00-00
Unavailable
72
NUT,FLANGE(J10)
95702-08500-00
Unavailable
73
WASHER, PLATE
90201-06018-00
Unavailable
74
PIN, COTTER
91490-20025-00
Unavailable
