Yamaha PZ480STC (PHAZER MOUNTAIN LITE) 8BH6 1999 BRAKE Diagram

#

Description
Price

1

DISC,BRAKE

87F-25711-01-00

Unavailable

2

KEY

8J7-25848-00-00

$4.77

3

CALIPER BODY COMP.1

86M-25730-01-00

Unavailable

4

SCREW, ADJUSTING 1

86M-25738-00-00

$8.91

5

. LEVER, BRAKE

86M-25726-01-00

Unavailable

6

SHIM, CALIPER

86M-25827-00-00

$2.37

7

LOCK, ONE WAY 2

86M-25773-00-00

$8.91

8

RATCHET, ADJUSTING

86M-25771-00-00

$6.58

9

COVER

86M-25772-00-00

$35.52

10

BOLT, CALIPER

86M-25818-00-00

$4.29

11

. BRACKET, CALIPER

86M-25721-00-00

Unavailable

12

BOLT 3

86M-25826-00-00

$1.95

13

. SPRING, COMPRESSION

86M-25743-00-00

Unavailable

14

. SPRING, STOPPER

86M-25714-00-00

Unavailable

15

PLATE, BACK UP

86M-25733-00-00

$12.78

16

BOLT, FITTING

86M-25833-00-00

$0.28

17

PIN 2

86M-25744-00-00

$1.27

18

BOLT, FLANGE(8AB)

95817-10050-00

$5.03

19

PAD, CALIPER 2

89J-25911-00-00

$50.02

20

PAD, CALIPER 2

89J-25811-00-00

$23.38

21

BRACKET, OIL TANK 2

87F-2193F-00-00

Unavailable
