Description

Price

1

PANEL, INSTRUMENT

8V0-77711-00-00

Unavailable

2

PANEL, INSTRUMENT (8V0-77712-00)

8V0-77712-01-00

Unavailable

3

INDICATOR 1

8U9-77741-00-00

Unavailable

4

INDICATOR 2

8U9-77742-00-00

Unavailable

5

GROMMET, INSTR PNL

8V0-77740-00-00

Unavailable

6

LOUVER 1

8V0-77131-00-00

Unavailable

7

LOUVER 2

8V0-77132-00-00

Unavailable

8

REFLECTOR 1

8V0-7716E-00-00

Unavailable

9

SHIELD 1

8V0-77731-00-00

Unavailable

10

SCREW, BINDING

98907-05012-00

$8.49

11

SCREW, BINDING

98907-05016-00

$8.49

12

WASHER, PLATE 8067717800

90201-05029-00

$8.49

13

BRACKET 1

(8V0-77721-00-00)

Unavailable

14

SCREW, TAPPING(3JP)

97707-50612-00

$7.49

15

WASHER(1RW)

92907-05600-00

$3.78

16

LABEL, WARNING 3

80L-77763-00-00

Unavailable

17

ORMNT, INSTR PNL 1PANEL 1

8V0-77715-00-00

Unavailable

Yamaha PZ480H (PHAZER) 1984 INSTRUMENT PANEL Diagram

PANEL, INSTRUMENT

PANEL, INSTRUMENT (8V0-77712-00)

INDICATOR 1

INDICATOR 2

GROMMET, INSTR PNL

LOUVER 1

LOUVER 2

REFLECTOR 1

SHIELD 1

SCREW, BINDING

SCREW, BINDING

WASHER, PLATE 8067717800

BRACKET 1

SCREW, TAPPING(3JP)

WASHER(1RW)

LABEL, WARNING 3

ORMNT, INSTR PNL 1PANEL 1
