Yamaha PW50K (PW50) 1983 CRANKCASE Diagram

#

Description
Price

1

CRANKCASE 1

4X4-15111-00-00

Unavailable

2

PIN, DOWEL

99530-12016-00

$4.89

3

SCREW PAN HEAD

98580-06545-00

$5.60

4

CRANKCASE 2

4J2-15121-00-00

Unavailable

5

HOLDER

3L5-15128-00-00

Unavailable

6

SCREW, PAN HEAD(62J)

97885-06012-00

Unavailable

7

DAMPER, ENGINE MOUNT

2E9-15316-00-00

$27.99

8

COVER, GENERATOR

4J2-15415-00-00

$37.99

9

SCREW, PAN HEAD(6B0)

97885-05016-00

Unavailable

10

COVER, CRANKCASE 2

4X4-15421-02-00

Unavailable

11

BUSH 1

3L5-17112-02-00

$15.49

12

PIN, DOWEL

99530-12016-00

$4.89

13

GASKET, CRANKCASE COVER 1

3L5-15451-12-00

$18.49

14

SCREW, PAN

98507-06035-00

$8.49

15

SCREW, PAN HEAD (76T)

98517-06025-00

$3.77

16

BOLT, FLANGE

95817-08075-00

Unavailable

17

WASHER, PLATE 3411117500

90201-08087-00

Unavailable

18

PLUG, OIL

4J2-15363-10-00

Unavailable

19

O-RING (26H)

93210-14579-00

Unavailable

20

BOLT (4J2)

90109-08582-00

Unavailable

21

PLATE

4J2-15113-00-00

Unavailable

22

SCREW, PAN HEAD(62J)

97885-06012-00

Unavailable

23

WASHER, SPRING

92995-06100-00

Unavailable

24

PROTECTOR

4X4-15491-00-00

Unavailable

25

CLAMP 2

4X4-15484-00-00

Unavailable
