Kawasaki Prairie 700 4x4 Drive Shaft-Rear Diagram
#
11065
CAP
11065-1260
$4.57
13168
LEVER,BRAKE
13168-1687
Unavailable
13216
GEAR-COMP,RR,8T
13216-0002
Unavailable
13271
PLATE,CAM
13271-1367
Unavailable
13310
SHAFT-ASSY,RR DRIVE SHAFT
13310-1026
$238.79
14057
CASE-COMP-GEAR
14057-0001
$265.35
14091
COVER,RH
14091-0028
$73.84
14091A
COVER,LH
14091-1422
$63.89
41068
AXLE
41068-1453
$471.28
41080
DISC,FRICTION
41080-1482
$49.80
41080A
DISC,PRESSURE
41080-1483
$18.80
41080B
DISC,SEPARATER
41080-1484
$18.80
49006
BOOT,RR DRIVE SHAFT
49006-1358
$18.28
49022
GEAR-BEVEL,RR,35T
49022-0003
$240.88
55020
GUARD,RR CASE
55020-0038
Unavailable
92009
SCREW-SET-SOCKET,75X10
92009-1667
$88.39
92037
CLAMP-HOSE
92037-1104
$1.45
92043
PIN,3X35
92043-1617
$2.41
92045
BEARING-BALL,BX30-1C3 UR3
92045-0026
$51.38
92049
SEAL-OIL,HTC40X58X8
92049-0012
$18.05
92049A
SEAL-OIL,SC40X52X7
92049-0013
$11.69
92055
RING-O,156.3X3.7
92055-0004
$13.55
92055A
RING-O,25.7X2.4
92055-1136
$5.00
92065
GASKET,8.5X16X1
92065-023
$3.88
92066
PLUG
92066-1303
$12.96
92140
BALL,D/O#12
92140-1064
$2.39
92145
SPRING,RR DRIVE SHAFT
92145-1300
$2.90
92145A
SPRING,RR BRAKE
92145-1301
$1.84
92151
BOLT,8X30
92151-1908
$2.80
92151A
BOLT,10X35
92151-1909
$3.26
92153
BOLT,12X35
92153-0311
$4.18
92170
CLAMP
92170-1763
$5.70
92171
CLAMP
92171-1383
$4.40
92180
SHIM,55X64X0.15
92180-1417
Unavailable
92180A
SHIM,55X64X0.20
92180-1418
Unavailable
92180B
SHIM,55X64X0.50
92180-1419
Unavailable
92180C
SHIM,55X64X0.80
92180-1420
Unavailable
92180D
SHIM,55X64X1.00
92180-1421
Unavailable
92180E
SHIM,55X64X1.20
92180-1422
Unavailable
92180F
SHIM,60X72X0.15
92180-1423
Unavailable
130
BOLT-FLANGED,8X16
130G0816
$1.10
601
BEARING-BALL
601A6011
$43.66
671
O RING
671D2585
$7.98
92180G
SHIM,60X72X0.20
92180-1424
Unavailable
92180H
SHIM,60X72X0.50
92180-1425
Unavailable
92180I
SHIM,60X72X0.80
92180-1426
Unavailable
92180J
SHIM,60X72X1.00
92180-1427
Unavailable
92180K
SHIM,60X72X1.20
92180-1428
Unavailable
92191
TUBE,BREATHER
92191-1595
$18.52
92210
NUT,30MM
92210-1294
$40.82
