1998 Kawasaki Prairie 400 Gear Change Drum/shift Fork Diagram

← All diagrams

Find the part on the Gear Change Drum/shift Fork diagram for your 1998 Kawasaki Prairie 400, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1998 Kawasaki Prairie 400 Gear Change Drum/shift Fork Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

13107

SHAFT,IDLER

13107-1363

1
Out of stock

13260

GEAR,FORWARD/LOW,24T

13260-1578

1
Out of stock

13260A

GEAR,COUNTER HI,37T

13260-1642

1
Out of stock

13260B

GEAR,IDLER,33T

13260-1671

1
Out of stock

39135

SPROCKET-DRIVEN,33T

39135-1056

1
Out of stock

92022

WASHER,25.3X32X1

92022-1800

1

$4.42

In stock

92033

RING-SNAP,24MM

92033-026

1

$6.98

In stock
