Kawasaki Prairie 300 4X4 Gear Change Drum/Shift Fork(s) Diagram

Description

Price

13107

SHAFT,IDLER

13107-1414

Unavailable

13139

SHIFTER,FORWARD HI&REVERSE

13139-1086

$102.68

13260

GEAR,FORWARD HIGH,43T

13260-1766

$144.40

13260A

GEAR,FORWARD LOW,48T

13260-1767

$144.40

13260B

GEAR,IDLE SHAFT,36T

13260-1769

$144.40

39135

SPROCKET-DRIVEN,REVERSE,37T

39135-1059

$150.74

92022

WASHER,28.1X34X1.0

92022-1731

$7.29

92026

SPACER,20.3X30X1.8

92026-1066

$9.71

92033

RING-SNAP,24MM

92033-026

$8.79

92033A

RING-SNAP,25.9X30.6X1.2

92033-1037

$4.65

92200

WASHER,24.2X32X0.50

92200-1400

$2.93

92200A

WASHER,24.2X32X1.00

92200-1412

$2.63
