Kawasaki Police 1000 FRONT MASTER CYLINDER (KZ1000-C1) Diagram

#

Description
Price

1

CYLINDER ASSY,MSTR,F

43015-1009

Unavailable

2

CAP,OIL CUP

43026-003

Unavailable

3

PLATE-MASTER CYLINDE

43027-001

Unavailable

4

DIAPHRAGM

43028-003

Unavailable

5

BOLT

43033-004

Unavailable

6

LEVER,FRONT BRAKE

43029-003

$105.99

7

NUT 6MM

312B0600

$0.72

8

HOLDER-MASTER CYL

43034-001

$39.96

9

WASHER PLAIN 6MM

411B0600

$2.84

10

BOLT HEX HEAD 6X25

110N0625

$5.46

11

REPAIR ASY,MASTER CY

43073-005

$112.38

12

VALVE ASSY, CHECK

43017-002

$8.33

13

SPRING ASSY, RETURN

43018-002

$39.46

14

CUP, PRIMARY

43019-002

$25.99

15

PISTON ASSY

43072-001

Unavailable

16

STOPPER-PISTON

43022-001

Unavailable

17

CIRCLIP-TYPE-C,18MM

481J1800

$4.31

18

BOOTS

43024-001

$7.20

19

STOPPER-BOOTS

43025-001

Unavailable

20

WASHER-LOCK,8MM

43031-001

Unavailable

21

NUT,8MM

311B0800

$0.67

22

BOLT,LEVER ADJUSTING

43030-003

Unavailable

23

WASHER,10.5X15X1.5

43067-001

$2.15

24

HOSE,FRONT BRAKE

43059-022

Unavailable

25

BOLT,OIL,L=23

92002-1888

$5.48

26

BOOT,DUST

49006-1041

$11.49

27

BOLT,HEX HEAD,6X45

110N0645

$3.58

28

WASHER SPRING 6MM

461F0600

$0.69

29

WASHER PLAIN 6MM

411B0600

$2.84

30

JOINT,FOUR WAY

43075-002

$42.47

31

SWITCH-FRONT BRAKE

43065-001

Unavailable

32

CAP,FRONT BRK SWITCH

11012-1037

Unavailable

33

HOSE,CALIPER BRAKE

43059-033

Unavailable

34

BRACKET

11034-1041

Unavailable

35

BRACKET,BRK HOSE,R.H

11034-1063

Unavailable

36

GROMMET,HOSE CLAMP

43064-006

$4.31
