- POLARIS XPEDITION ADV 5 NORTHSTAR (R01) - G25GZW99AB/AP/AK/BB/BP/BK
BODY, DOOR ASSEMBLY, FRONT
Polaris POLARIS XPEDITION ADV 5 NORTHSTAR (R01) - G25GZW99AB/AP/AK/BB/BP/BK BODY, DOOR ASSEMBLY, FRONT Diagram
#
-
ASM-DOOR,POWER,LH [INCLUDES 1-27]
2637917
$1,759.99
-
ASM-DOOR,POWER,RH [INCLUDES 1-27]
2637918
$1,759.99
1
WELD-FR,HALF,FRONT,LH,BLK [INCLUDES 36 & 37]
1027132-458
$742.49
1
WELD-FR,HALF,FRONT,RH,BLK [INCLUDES 36 & 37]
1027133-458
$742.49
2
ASM-REGULATOR,POWER WINDOW,LH
2637925
$281.59
2
ASM-REGULATOR,POWER WINDOW,RH
2637926
$281.59
3
GLASS-WINDOW,DOOR,FRNT,LH
2637929
$82.49
3
GLASS-WINDOW,DOOR,FRNT,RH
2637930
$82.49
4
PNL-DOOR,INT,LH,POWER,BLK
5456867-070
$327.99
4
PNL-DOOR,INT,RH,POWER,BLK
5456868-070
$327.99
5
PNL-DOOR,EXT,BASE,LH,BLK
5465166-070
$355.99
5
PNL-DOOR,EXT,BASE,RH,BLK
5465167-070
$355.99
6
HANDLE-GRAB,DOOR,BLK
5465274-070
$13.59
7
SEAL-EXTRSN,14.00X12.70,995MM
5526544-995
$43.99
8
CLIP-U SPEED NUT
7081305
$1.99
9
CABLE-DOOR,INTERNAL
7082665
$14.39
10
ASM-HANDLE,DOOR INNER
7082692
$39.99
11
ASM-ACTUATOR,EXT,LH
7083143
$71.99
11
ASM-ACTUATOR,EXT,RH
7083144
$71.99
12
BOLT-M6X1.0X20,PH/TX-OLIVE D
7518616
$1.49
12
BOLT-M6X1.0X20,PH/TX-OLIVE D
7518616
$1.49
13
SCR-TXBH-M8X1.25X20 10.9 ZTB
7527948-20
$2.39
14
SCR-TXPH-#14 X .75 HI-LO RIE
7519731
$3.99
15
SCR-TXTH-M8X1.25X20 8.8 ZB3 P3
7519997
$3.99
16
SCR-HXFL-M8X1.25X20 10.9ZFB P
7528211
$1.59
16
SCR-HXFL-M8X1.25X20 10.9ZFB P
7528211
$1.59
17
NUT-HXFL-M6X1.0 8 ZTB NYL
7548027
$1.59
18
RIVET-TUFLOK,.315-.325X.787
7661855
$1.49
18
RIVET-TUFLOK,.315-.325X.787
7661855
$1.49
19
ASM-HINGE,FRONT
2638401
$23.99
20
SCR-M6X1.0X20,HXHD,FLG,TDFM,BK
7518529
$1.49
20
SCR-M6X1.0X20,HXHD,FLG,TDFM,BK
7518529
$1.49
21
ASM-LATCH,LH
7082930
$51.99
21
ASM-LATCH,RH
7082931
$51.99
22
CABLE-DOOR,EXTERNAL
7082663
$14.39
23
SEAL-BELTLINE,FRONT,A
5522389
$27.99
24
SEAL-BELTLINE,FRONT,B
5522390
$27.99
25
SEAL-WINDOW,RUN CHANNEL,FRONT
5526360
$55.99
26
SEAL-BULB,FRONT,FULL DOOR
5526487
$87.99
27
WELD-FRAME,WINDOW,FRONT,LH
1026476
Unavailable
27
WELD-FRAME,WINDOW,FRONT,RH
1026477
Unavailable
28
ASM-STRIKER
2638472
$27.99
29
NUT-HXFL-M8X1.25 8 ZTB NYL
7548028
$2.39
30
SCR-HXFL-M8X1.25X25 10.9 ZFB
7521332-25
$3.73
31
PNL-DR,EXT,CREW,PNT,LH,M.GREEN [AB] [BB] [MOSS GREEN]
5465121-975
$311.99
31
PNL-DR,EXT,CREW,PNT,LH,M.S.GR [AK] [BK] [SUPER GRAPHITE]
5465121-894
$311.99
31
PNL-DR,EXT,CREW,PNT,LH,MD BLUE [AP [BP] [MIDNIGHT BLUE]
5465121-469
$311.99
31
PNL-DR,EXT,CREW,PNT,RH,M.GREEN [AB] [BB] [MOSS GREEN]
5465122-975
$311.99
31
PNL-DR,EXT,CREW,PNT,RH,M.S.GR [AK] [BK] [SUPER GRAPHITE]
5465122-894
$311.99
31
PNL-DR,EXT,CREW,PNT,RH,MD BLUE [AP [BP] [MIDNIGHT BLUE]
5465122-469
$311.99
32
HANDLE-ACTUATOR,EXT [INCLUDES SCREW]
5459569
$31.99
32
SCR-HANDLE,DOOR
7528227
$2.39
33
HANDLE-ACTUATOR,EXT,PLUG
5457811
$10.39
34
ASM-ACTUATOR,EXT,CORE,7
7082789
$75.99
35
BRKT-STRAP,LIMIT
5271393
$5.59
36
WIREFORM-HINGE,DOOR
5345470
$4.79
37
RIVET-3/16-.090-.290
7661637
$1.49
